Baldor EM2333T-BG AC Motors
Shaft Grounding Motor - 15 hp, 1800 rpm, 3 ph, 230/460 V, 254T Frame, TEFC (Totally Enclosed Fan Cooled) Enclosure, 60 Hz, 1765 rpm Base, Rigid Base Mount, Continuous Duty
ITEM #6907a9c7ad9cc32ae130c51e MFR #EM2333T-BG SKU #YLSGKLE43LR3P1H
Hızlı Özellikler
Motor Category: Shaft Grounding Motor
Motor Phase: 3 ph
Motor Horsepower: 15 hp
Synchronous Rpm: 1800 rpm
Motor Supply Voltage: 230/460 V
Frame Size: 254T
Genel Bakış
Shaft Grounding Motor - 15 hp, 1800 rpm, 3 ph, 230/460 V, 254T Frame, TEFC (Totally Enclosed Fan Cooled) Enclosure, 60 Hz, 1765 rpm Base, Rigid Base Mount, Continuous Duty
Teknik Özellikler
Motor Category Shaft Grounding Motor
Motor Phase 3 ph
Motor Horsepower 15 hp
Synchronous Rpm 1800 rpm
Motor Supply Voltage 230/460 V
Frame Size 254T
Enclosure Type TEFC (Totally Enclosed Fan Cooled)
Frequency Rating 60 Hz
Duty Condition Type Continuous Duty
Base RPM 1765 rpm
Thermal Protection None
Full Load Current 18.10 A
Starting Method Direct on Line (DOL)
KVA Code H
Full Load Efficiency 92.40 %
Motor Poles 4-pole
Ambient Temperature Range 40 °C
Description Keyword 15 hp
Shaft Rotation Reversible
Shaft Diameter 1.6250 in
Overall Length C Dimension 23.30 in
Frame Material Iron
Insulation Class H
Service Factor 1.15
Standards Met CSA, CSA EEV, UR
Weight 274 lbs
Manufacturer Upc Number 781568720172
UPC_NO 781568720172
Mounting Type Rigid Base
Product Type Air Handling (HVAC) Motors
