Baldor D2505P DC Motors
DC Electric Motor - Shunt Wound, Brushed, 240 V, 1750 rpm rpm, TEFC (Totally Enclosed Fan Cooled), 1810AT Frame
ITEM #6907af6bad9cc32ae1311a6b MFR #D2505P SKU #YLSDQABNLDZBRB4
Hızlı Özellikler
Motor Family: Shunt Wound
Motor Type: Brushed
Motor Horsepower: 5 hp
DC Armature Voltage: 240 V
Base RPM: 1750 rpm
Enclosure Type: TEFC (Totally Enclosed Fan Cooled)
Genel Bakış
DC Electric Motor - Shunt Wound, Brushed, 240 V, 1750 rpm rpm, TEFC (Totally Enclosed Fan Cooled), 1810AT Frame
Teknik Özellikler
Motor Family Shunt Wound
Motor Type Brushed
Motor Horsepower 5 hp
DC Armature Voltage 240 V
Base RPM 1750 rpm
Enclosure Type TEFC (Totally Enclosed Fan Cooled)
NEMA / IEC Frame Size 1810AT
DC Field Voltage 150/300 V
Armature Full Load Current 17.6 A
Field Full Load Current 0.68 A
Overall Length C Dimension 23.88 in
Insulation Class F
Standards Met NEMA
Drive End Bearing 6206
Weight 333.00 lbs
Opposite Drive End Bearing 6205
Recommended Control Bc20H205-Cl
Typical Application Conveyors, Packaging Machinery and Other Applications for Scar Drive Motors
Wattage 3730.0 W
Manufacturer Product Page http://www.baldor.com/products/detail.asp?1=1&page=3&catalogonly=1&catalog=D2505P&product=DC+Motors&family=General+Purpose%7Cvw%5FDCMotors%5FGeneralPurpose&enclosure=TEFC#
UPC_NO 781568136126
