Baldor CESWDM3611T
General Purpose Washdown Duty Motor (Paint Free) - 3 hp, 1800 rpm, 3 ph, 230/460 V, 182TC Frame, TEFC (Totally Enclosed Fan Cooled) Enclosure, 60 Hz, 1760 rpm Base, C-Face / Foot Mount
ITEM #6907aa5fad9cc32ae130d120 MFR #CESWDM3611T SKU #YLSSNJRT4VQ06R7
Hızlı Özellikler
Motor Category: General Purpose Motor (Paint Free)
Motor Phase: 3 ph
Motor Horsepower: 3 hp
Synchronous Rpm: 1800 rpm
Motor Supply Voltage: 230/460 V
Frame Size: 182TC
Genel Bakış
General Purpose Washdown Duty Motor (Paint Free) - 3 hp, 1800 rpm, 3 ph, 230/460 V, 182TC Frame, TEFC (Totally Enclosed Fan Cooled) Enclosure, 60 Hz, 1760 rpm Base, C-Face / Foot Mount
Özellikler ve Avantajlar
- Moisture-resistant insulation system
- Sealed ball bearings with moisture-resistant grease
- Rotating non-contact labyrinth seal on output shaft extension
- Neoprene gaskets
- Special processed cast endplates
- 300 Series stainless steel motor frame, base, shaft and hardware
- Applications: Food processing, packaging and other outdoor applications, severe environments where motors are washed on a regular basis
Teknik Özellikler
Motor Category General Purpose Motor (Paint Free)
Motor Phase 3 ph
Motor Horsepower 3 hp
Synchronous Rpm 1800 rpm
Motor Supply Voltage 230/460 V
Frame Size 182TC
Enclosure Type TEFC (Totally Enclosed Fan Cooled)
Frequency Rating 60 Hz
Duty Condition Type Continuous Duty, Washdown Duty
Base RPM 1760 rpm
Full Load Current 4.00 A
Full Load Efficiency 89.50 %
Amps @ Voltage 8.1 A @ 208 V; 8.0 A @ 230 V; 4.0 A @ 460 V
Volts @ Frequency 208 V @ 60 Hz; 230 V @ 60 Hz; 460 V @ 60 Hz
Shaft Diameter 1.1250 in
Overall Length C Dimension 16.56 in
Service Factor 1.15
Frame Material Stainless Steel
Insulation Class F
IP Rating 55
Standards Met CSA EEV, UR, CSA
Harmonization Code 8501.52.4000
Weight 80 lbs
Applications Food processing, packaging and outdoor applications.
Additional Details Sealed ball bearings with moisture-resistant grease. Rotating noncontact labyrinth seal on output shaft extension. Moisture resistant insulation system. Neoprene gaskets. Special processed cast endplates. 300 series stainless steel motor frame, base, shaft and hardware. No exterior paint.
Manufacturer Catalog http://www.baldor.com/mvc/DownloadCenter/Files/CA501
Manufacturer Product Page http://www.baldor.com/catalog/CESWDM3611T
UPC_NO 781568490921
Wiring Diagram https://www.baldorvip.com/servlet/productInfoPacket?nameplate=X&layoutdiagram=X&electrical=X&connectiondiagram=X&language=E&matnr=CESWDM3611T&vkorg=BEC
Instructional Video https://youtu.be/j-mFjRPjiFU?list=PLUJtYxZcxl_oZa19yqrOGvU3YxQu5APRV
Mounting Type C-Face / Foot
Product Type Washdown Duty Motors
