Baldor CEFWWDM3546 AC Motors
General Purpose Washdown Duty Motor (Painted) - 1 hp, 1800 rpm, 3 ph, 208-230/460 V, 56C Frame, TEFC (Totally Enclosed Fan Cooled) Enclosure, 60 Hz, 1770 rpm Base, C-Face / Foot Mount
ITEM #6907cf396c556f461693c8b5 MFR #CEFWWDM3546 SKU #YLSC37N6VWQ6EPK
Hızlı Özellikler
Motor Category: General Purpose Motor (Painted)
Motor Phase: 3 ph
Motor Horsepower: 1 hp
Synchronous Rpm: 1800 rpm
Motor Supply Voltage: 208-230/460 V
Frame Size: 56C
Genel Bakış
General Purpose Washdown Duty Motor (Painted) - 1 hp, 1800 rpm, 3 ph, 208-230/460 V, 56C Frame, TEFC (Totally Enclosed Fan Cooled) Enclosure, 60 Hz, 1770 rpm Base, C-Face / Foot Mount
Teknik Özellikler
Motor Category General Purpose Motor (Painted)
Motor Phase 3 ph
Motor Horsepower 1 hp
Synchronous Rpm 1800 rpm
Motor Supply Voltage 208-230/460 V
Frame Size 56C
Enclosure Type TEFC (Totally Enclosed Fan Cooled)
Frequency Rating 60 Hz
Duty Condition Type Continuous Duty, Washdown Duty
Base RPM 1770 rpm
Full Load Efficiency 85.50 %
Amps @ Voltage 3.1 A @ 208 V; 3.0 A @ 230 V; 1.5 A @ 460 V
Volts @ Frequency 208 V @ 60 Hz; 230 V @ 60 Hz; 460 V @ 60 Hz
Description Keyword 1 hp
Shaft Diameter 0.6250 in
Overall Length C Dimension 12.35 in
Service Factor 1.15
Frame Material Steel
Insulation Class F
IP Rating 56
Standards Met CSA EEV, UR, CSA
Harmonization Code 8501.51.6040
Weight 37 lbs
Applications Wet or humid environments in food and beverage processing facilities in which equipment is cleaned on a regular basis.
Additional Details Labyrinth seal on each end of motor provides an added level of protection from washdown spray, same size bearings on each end of motor, easily removable drain plugs, 300 series stainless steel shaft and hardware, lead-sealing neoprene gaskets. Class F insulated motor with 1.15 service factor or higher that operates within class “B” temperature limits at rated horsepower.
Manufacturer Catalog http://www.baldor.com/mvc/DownloadCenter/Files/CA501
Manufacturer Product Page http://www.baldor.com/catalog/CEFWWDM3546
UPC_NO 781568688298
Wiring Diagram https://www.baldorvip.com/servlet/productInfoPacket?nameplate=X&layoutdiagram=X&electrical=X&connectiondiagram=X&language=E&matnr=CEFWWDM3546&vkorg=BEC
Instructional Video https://youtu.be/j-mFjRPjiFU?list=PLUJtYxZcxl_oZa19yqrOGvU3YxQu5APRV
Mounting Type C-Face / Foot
Product Type Washdown Duty Motors
