Baldor CDPT3455 DC Motors
DC Electric Motor - Permanent Magnet, Brushed, 180 V, 1750 rpm rpm, TEFC (Totally Enclosed Fan Cooled), 56C Frame
ITEM #6907b012ad9cc32ae1311e19 MFR #CDPT3455 SKU #YLS6CDYZM6JBFEA
Hızlı Özellikler
Motor Family: Permanent Magnet
Motor Type: Brushed
Motor Horsepower: 1 hp
DC Armature Voltage: 180 V
Base RPM: 1750 rpm
Enclosure Type: TEFC (Totally Enclosed Fan Cooled)
Genel Bakış
DC Electric Motor - Permanent Magnet, Brushed, 180 V, 1750 rpm rpm, TEFC (Totally Enclosed Fan Cooled), 56C Frame
Teknik Özellikler
Motor Family Permanent Magnet
Motor Type Brushed
Motor Horsepower 1 hp
DC Armature Voltage 180 V
Base RPM 1750 rpm
Enclosure Type TEFC (Totally Enclosed Fan Cooled)
NEMA / IEC Frame Size 56C
Armature Full Load Current 5 A
Overall Length C Dimension 17.52 in
Overall Dimensions 7.44
Insulation Class F
Standards Met NEMA
Drive End Bearing 6203
Weight 50.00 lbs
Opposite Drive End Bearing 6203
Recommended Control Bc140
Typical Application Conveyors and Metering Pumps Where Precise Speed Regulation is Required
Wattage 746.0 W
Overall Depth 18.9 in
Manufacturer Product Page http://www.baldor.com/products/detail.asp?1=1&page=1&catalogonly=1&catalog=CDPT3455&product=DC+Motors&family=Integral+Tach%7Cvw%5FDCMotors%5FIntegralTach
UPC_NO 781568133767
Overall Height 7.44 in
Overall Width 6.75 in
