Baldor CDPT3445 DC Motors
DC Electric Motor - Permanent Magnet, Brushed, 90 V, 1750 rpm rpm, TEFC (Totally Enclosed Fan Cooled), 56C Frame
ITEM #6907b012ad9cc32ae1311e1a MFR #CDPT3445 SKU #YLS1RC1GBZGGIQX
Hızlı Özellikler
Motor Family: Permanent Magnet
Motor Type: Brushed
Motor Horsepower: 1 hp
DC Armature Voltage: 90 V
Base RPM: 1750 rpm
Enclosure Type: TEFC (Totally Enclosed Fan Cooled)
Genel Bakış
DC Electric Motor - Permanent Magnet, Brushed, 90 V, 1750 rpm rpm, TEFC (Totally Enclosed Fan Cooled), 56C Frame
Teknik Özellikler
Motor Family Permanent Magnet
Motor Type Brushed
Motor Horsepower 1 hp
DC Armature Voltage 90 V
Base RPM 1750 rpm
Enclosure Type TEFC (Totally Enclosed Fan Cooled)
NEMA / IEC Frame Size 56C
Armature Full Load Current 10 A
Overall Length C Dimension 17.52 in
Insulation Class F
Standards Met NEMA
Drive End Bearing 6203
Weight 50.00 lbs
Opposite Drive End Bearing 6203
Recommended Control Bc140
Typical Application Conveyors and Metering Pumps Where Precise Speed Regulation is Required
Wattage 746.0 W
Manufacturer Product Page http://www.baldor.com/products/detail.asp?1=1&page=1&catalogonly=1&catalog=CDPT3445&product=DC+Motors&family=Integral+Tach%7Cvw%5FDCMotors%5FIntegralTach
UPC_NO 781568133750
