Baldor CDP3410-V24 DC Motors
DC Electric Motor - Permanent Magnet, Brushed, 24 V, 1800 rpm rpm, TENV (Totally Enclosed Non-Ventilated), 56C Frame
ITEM #6907adf1ad9cc32ae131024c MFR #CDP3410-V24 SKU #YLSEO6Y84NL1ECY
Hızlı Özellikler
Motor Family: Permanent Magnet
Motor Type: Brushed
Motor Horsepower: 1/4 hp
DC Armature Voltage: 24 V
Base RPM: 1800 rpm
Enclosure Type: TENV (Totally Enclosed Non-Ventilated)
Genel Bakış
DC Electric Motor - Permanent Magnet, Brushed, 24 V, 1800 rpm rpm, TENV (Totally Enclosed Non-Ventilated), 56C Frame
Özellikler ve Avantajlar
- NEMA C-face
- Class F insulation
- Double sealed ball bearings
- Top-mounted terminal studs
- Not tach adaptable
- 1/4 HP to 1/2 HP are TENV
- 3/4 HP to 1 HP are TEFC
- Applications: Battery operation for portable pumps, fans, augers, winches and lifts
Teknik Özellikler
Motor Family Permanent Magnet
Motor Type Brushed
Motor Horsepower 1/4 hp
DC Armature Voltage 24 V
Base RPM 1800 rpm
Enclosure Type TENV (Totally Enclosed Non-Ventilated)
NEMA / IEC Frame Size 56C
Armature Full Load Current 10.6 A
Insulation Class F
Standards Met NEMA
Weight 29.00 lbs
Manufacturer Product Page http://www.baldor.com/products/detail.asp?1=1&catalog=CDP3410-V24&product=DC+Motors&family=General+Purpose%7Cvw%5FDCMotors%5FGeneralPurpose
UPC_NO 781568388112
