How can I get a price quote for Weatherhead (Danfoss) H56904?

You can request a fast quote for Weatherhead (Danfoss) H56904 from Yılsa Engineering. Reference part number YLSSX7IA7XXW9Q6. Submit a request via the contact or quote form and our team replies shortly with price and lead time.

Is Weatherhead (Danfoss) H56904 in stock and what is the delivery time?

Yılsa Engineering sources products as genuine items through a wide supplier network. Typical lead time is 7-21 days, with 1-3 business days domestic transit in Türkiye. Current status is confirmed in the quote.

Is Weatherhead (Danfoss) H56904 genuine and new?

Yes. This Weatherhead (Danfoss) product is supplied genuine and brand-new, sold with invoice under Yılsa Engineering assurance.

How do I get the datasheet and technical specs for Weatherhead (Danfoss) H56904?

Key technical specifications are listed on the product page. For the full datasheet, dimensions and compatibility, simply contact Yılsa Engineering.

Click to zoom

Photo may not represent actual item. Refer to name and product specs for all details.

Weatherhead (Danfoss) H56904

Weatherhead H569 Series Engine and Fuel Hose and Tubing

Weatherhead (Danfoss)MFR # H56904SKU # YLSSX7IA7XXW9Q6

Abrasion ResistancePremium

Air Brake Temperature Range-40 - 200 F

Air Temperature Range-40 - 212 F

Bend Radius3 in

Burst Pressure12000 psi

ColorBlue

Have questions?Chat on WhatsApp

About This Product

Weatherhead (Danfoss) H56904 (Weatherhead H569 Series Engine and Fuel Hose and Tubing) is supplied genuine and fast by Yılsa Engineering. Get an instant quote for Weatherhead (Danfoss) H56904 — price, stock availability and technical specifications.

Features and Benefits

Highly abrasion resistant cover
Small number of hoses for many fuel options
Proven reliability with high temperature resistance

Weatherhead (Danfoss) H56904

Genuine, certified Weatherhead (Danfoss) product
Fast sourcing through a worldwide supply network
Product selection and compatibility support from our technical team
Equivalent and alternative product suggestions
Quotation and lead time tailored to your request

Specifications

Abrasion ResistancePremium

Air Brake Temperature Range-40 - 200 F

Air Temperature Range-40 - 212 F

Bend Radius3 in

Burst Pressure12000 psi

ColorBlue

Compatible Fittings069 E

Dash Size-4

Hose Covering MaterialFiber

Hydraulic Fluid Temperature Range-55 - 302 F

Inner Diameter0.19 in

Inner Tube MaterialCPE

Inside Diameter0.19 in

Length50.00 ft

Manufacturer Upc Number725975564950

Max Operating Temperature200 °F

Maximum Temperature200 °F

Maximum Working Pressure3000 psi

Minimum Bend Radius3.00 in

Min Operating Temperature-40 °F

Minimum Temperature-40 °F

Operating Pressure3000 psi

Operating Temperature Range-55 to 302 °F

Outer Diameter0.52 in

Outside Diameter0.52 in

Overall Length50.00 ft

Product Types3 Braid

Reinforcement TypeFiber and steel

Standards MetSAE 100R5, ABS, SAE J1402

Tube Inner Diameter0.19 in

Tube MaterialCPE

TypeH569 Hydraulic hose

Typical ApplicationsAir brake truck, hydraulics, diesel fuel.

Wall Thickness0.33 in

Working Pressure3000 psi
