Weatherhead (Danfoss) H00908
Hydraulic General Purpose Low Pressure Hose - 1/2 in ID, 0.8 in OD, 400 psi Working Pressure, 1600 psi Burst Pressure, Synthetic Rubber Cover, Synthetic Rubber Tube
ITEM #6908a716869d50d7f60dfa9e MFR #H00908 SKU #YLSQ1VEALXAZ1ZB
Quick Specs
Nominal Hose Inner Diameter: 0.50 in
Nominal Hose Outer Diameter: 0.8 in
Manufacturer Upc Number: 725975009888
Working Pressure: 400 psi
Applications: Air and multi purpose.
Pressure Rating: 400 psi
Overview
Hydraulic General Purpose Low Pressure Hose - 1/2 in ID, 0.8 in OD, 400 psi Working Pressure, 1600 psi Burst Pressure, Synthetic Rubber Cover, Synthetic Rubber Tube
Features and Benefits
- Maximum durability under harsh operating conditions
- Robust construction able to withstand highest pressures
- System engineered to extend hose assembly life
Specifications
Nominal Hose Inner Diameter 0.50 in
Nominal Hose Outer Diameter 0.8 in
Manufacturer Upc Number 725975009888
Working Pressure 400 psi
Applications Air and multi purpose.
Pressure Rating 400 psi
Burst Pressure 1600 psi
Inner Tube Material Synthetic Rubber
Width 0.80 in
Hose Reinforcement Material Textile
Hose Covering Material Synthetic Rubber
Hose Reinforcement Type 1 Braid of Textile
Operating Temperature Range -40 to 212 °F
UPC_NO 725975009888
Color Black
Overall Length 50.00 ft
Minimum Bend Radius 4.00 in
Wall Thickness 0.1406 in
NMFC Number 70
Segment Code C
Hose Weight 9.00 lb
Compatible Fittings E, 009H
Height 0.80 in
Manufacturer Compatibility This product can only be used with other Weatherhead products.
Standards Met SAE 100R6
Bend Radius 4 in
Inside Diameter 0.5 in
Max Pressure 400 psi
Outside Diameter 0.8 in
Hose Length 50.00 ft
Abrasion Resistance Standard
Application Air and multi purpose.
Conductivity Conductive
Construction 1 Ply Braid
Lay Line Style Ink Jet
Trade Name/Number H009 Series
Tube Material Synthetic Rubber
Working Temperature Max 212 °F
Working Temperature Min -40 °F
Cover Color Black
Cover Material Synthetic Rubber
Length 50.00 ft
Tube Materials Synthetic Rubber
Weight 9.00 lb
Manufacturer Catalog Number H00908
Trade / Brand Name H009 Series
Description Weatherhead H009 Series Rubber Hydraulic Braided Hose
Hose Dash Size 8
Maximum Operating Pressure 400 psi
Maximum Working Pressure 400 psi
Overall Weight 9.00 lb
Maximum Temperature 212 °F
Minimum Temperature -40 °F
