SMC KK130P-N02MS Quick Disconnect Couplings
S COUPLER
ITEM #6904bc63cdc3bc9ad23ed5c4 MFR #KK130P-N02MS SKU #YLS8Z288GGESFEW
Quick Specs
Application: Pneumatic
Coupling Component: Plug
Hose Connection Type: Male NPT
Thread Hose I.D. Tube O.D.: 1/4 in
Actual Thread Size: 1/4 – 18 NPT
Working Pressure Range: 100 to 250 psi
Overview
SMC KK130P-N02MS (S COUPLER) is supplied genuine and fast by Yilsa Engineering. Get an instant quote for SMC KK130P-N02MS — price, stock availability and technical specifications.
Features and Benefits
- Plug & socket variations: male & female thread, barb fitting, nut fitting, one-touch fitting
- Operating pressure range: 0 to 1.5MPa, one-touch fitting types : 0 to 1.0MPa
- Proof pressure: 2.0MPa
- Male thread types provided with sealant as standard
Specifications
Application Pneumatic
Coupling Component Plug
Hose Connection Type Male NPT
Thread Hose I.D. Tube O.D. 1/4 in
Actual Thread Size 1/4 – 18 NPT
Working Pressure Range 100 to 250 psi
Working Pressure 217 psi
Description Keyword 1/4 in NPT, 1/4 – 18 Male Thread
Weight 22.68 g
