Siemens 8MF1096-3VS4
SIVACON, Control panel Empty enclosure, according to IEC 62208, with ventilation openings, IP20, H: 2000 mm, W: 900 mm, T: 600 mm
product brand nameSIVACON
product designationEmpty control cabinet enclosure
design of the productaccording to IEC 62208
design of the surfacepowder-coated
design of the product EMC versionNo
protection class IPIP20
About This Product
SIVACON, Control panel Empty enclosure, according to IEC 62208, with ventilation openings, IP20, H: 2000 mm, W: 900 mm, T: 600 mm
Siemens 8MF1096-3VS4
- Genuine, certified Siemens product
- Fast sourcing through a worldwide supply network
- Product selection and compatibility support from our technical team
- Equivalent and alternative product suggestions
- Quotation and lead time tailored to your request
Specifications
Model
product brand nameSIVACON
product designationEmpty control cabinet enclosure
design of the productaccording to IEC 62208
design of the surfacepowder-coated
design of the product EMC versionNo
Protection class
protection class IPIP20
operating resource protection class1
Suitability
suitability for installation for metric dimensionsYes
suitability for integration surface-mounted installationYes
suitability for integration flush mountingNo
suitability for use for outside useNo
Appearance
RAL color number7 035
RAL color number (similar)7 035
colorlight grey
Product details
ventilation doorYes
mounting plateYes
rear doorNo
viewing doorNo
height-adjustable mounting plateYes
product feature of the enclosure housing can be lined upNo
Number
number of locking devices0
number of doors2
Mechanical Design
height2 000 mm
width900 mm
depth600 mm
19-inch installationNo
floor mountingYes
wall mountingNo
ventilation cross section inlet can be used816 cm²
ventilation cross section outlet can be used669 cm²
Net Weight174.36 kg
materialsteel
