Siemens 7KT1663

SENTRON, measuring device, 7KT PAC1600, LCD, L-L: 400 V, L-N: 230 V, 5 A, strd rail instr., 3-phase, M-Bus, apparent/ active/reactive energy, self-powered, screw terminals

SiemensMFR # 7KT1663SKU # YLSLJRJQIFQTRSQ

product brand nameSENTRON

product designationEnergy counter

product quality calibratedNo

type of signalS0

design of the energy counterSolid-state

design of the pulse outputElectrical

Have questions?Chat on WhatsApp

About This Product

SENTRON, measuring device, 7KT PAC1600, LCD, L-L: 400 V, L-N: 230 V, 5 A, strd rail instr., 3-phase, M-Bus, apparent/ active/reactive energy, self-powered, screw terminals

Siemens 7KT1663

Genuine, certified Siemens product
Fast sourcing through a worldwide supply network
Product selection and compatibility support from our technical team
Equivalent and alternative product suggestions
Quotation and lead time tailored to your request

Specifications

Model

product brand nameSENTRON

product designationEnergy counter

product quality calibratedNo

type of measured value detection load profileNo

type of signalS0

design of the energy counterSolid-state

design of the pulse outputElectrical

General technical data

minimum0.1 1/kVAh

maximum100 1/kVAh

type of the power supply networkthree-wire/four-wire

between L and L minimum323 V

between L and L maximum456 V

between N and L minimum187 V

between N and L maximum264 V

Protection class

protection class IPIP40

Main circuit

minimum45 Hz

maximum65 Hz

operational current rated value5 A

Suitability

suitability for useImport/export

Product function

backstopYes

blocking codeYes

Display and operation

display versiondigital

Number

number of characters that can be displayed10

Mechanical Design

number of modular width units4

fastening methodDIN rail device

Net Weight284 g
