Siemens 6XV1873-2A

FO Standard Cable GP (50/125/OM2), standard cable splittable, UL approval, max. length 1000 m minimum order quantity 20 m sold by the meter.

SiemensMFR # 6XV1873-2ASKU # CEY-8EF3B030B533

product brand nameSIMATIC NET

version of the assembled FO cablesold by the meter

cable designationAT-W(ZN)YY 2x1 G 50/125 OM2++

at 850 nm / maximum2.7 dB/km

at 1300 nm / maximum0.7 dB/km

at 850 nm600 GHz·m

Have questions?Chat on WhatsApp

About This Product

FO Standard Cable GP (50/125/OM2), standard cable splittable, UL approval, max. length 1000 m minimum order quantity 20 m sold by the meter.

Siemens 6XV1873-2A

Genuine, certified Siemens product
Fast sourcing through a worldwide supply network
Product selection and compatibility support from our technical team
Equivalent and alternative product suggestions
Quotation and lead time tailored to your request

Specifications

product brand nameSIMATIC NET

suitability for useCable for installation indoors and outdoors, UL approval

version of the assembled FO cablesold by the meter

cable designationAT-W(ZN)YY 2x1 G 50/125 OM2++

optical data

at 850 nm / maximum2.7 dB/km

at 1300 nm / maximum0.7 dB/km

at 850 nm600 GHz·m

at 1300 nm1200 GHz·m

mechanical data

number of fibers / per FOC core1

number of FO cores / per FOC cable2

version of the FO conductor fiberMulti-mode gradient fiber 50/125 µm, OM 2

design of the FOC coreHollow core, filled, diameter 1400 µm

design of the fiber-optic cablesegmentable

of the optical fibers50 µm

of the optical fiber sheath125 µm

of the FOC core sheath2.9 mm

symmetrical deviation / of the outer diameter of the FOC core sheath0.1 mm

width / of cable sheath7.4 mm

thickness / of cable sheath4.5 mm

of the fiber-optic cable coreQuartz glass

of the optical fiber sheathQuartz glass

of the FOC core sheathPVC

of the fiber-optic cable sheathPVC

of the strain reliefAramid fibers

of the FOC core sheathorange/black

of cable sheathgreen

with single bend / minimum permissible45 mm

with multiple bends / minimum permissible65 mm

during installation / short-term1200 N

during operation / maximum500 N

short-term shear force per length600 N/cm

continuous shear force per length400 N/cm

weight per length40 kg/km

ambient conditions

during operation-25 ... +80 °C

during storage-25 ... +80 °C

during transport-25 ... +80 °C

during installation-5 ... +50 °C

fire behaviorflame-resistant acc. to IEC 60332-1-2 and IEC 60332-3-22 (Cat. A)

class of burning behaviour / according to EN 13501-6Eca

to mineral oilacc. to IEC 60811-404 with test oil IRM 902 (acc. to ISO 1817), +70 °C, 4 h

to greaseconditional resistance

to waterconditional resistance

radiological resistance / to UV radiationresistant

product features, product functions, product components / general

halogen-freeNo

silicon-freeYes

product component / rodent protectionNo

for glass FOC / for 100BaseFX / for Industrial Ethernet / maximum5000 m

for glass FOC / for 1000BaseSX / for Industrial Ethernet / maximum750 m

for glass FOC / for 1000BaseLX / for Industrial Ethernet / maximum2000 m

for glass FOC / for 1000BaseLSX / for Industrial Ethernet / maximum2000 m

for glass FOC / for 10GBaseLX4 / for Industrial Ethernet / maximum300 m

for glass FOC / with PROFIBUS / maximum3000 m

standards, specifications, approvals

UL approvalYes; c(UL)us OFN FT4

RoHS conformityYes
