Siemens 6GT2811-7AD20-0AA0

Successor 6GT2811-8AD20-0AA0 start of delivery planned for 12/27 ETSI; Ethernet RJ45 PoE 4 antennas, 1x DI/DQ, 24 V DC; -25 to +55 °C; without accessories and antennas.

SiemensMFR # 6GT2811-7AD20-0AA0SKU # YLSDSW87LIHGH6Y

product brand nameSIMATIC RF

operating frequency865 ... 868 MHz

transmit power3 ... 2000 mW

for each external antenna / maximum2000 mW

for each external antenna / maximum4000 mW

product feature / multitag-capableYes

Have questions?Chat on WhatsApp

About This Product

Successor 6GT2811-8AD20-0AA0 start of delivery planned for 12/27 ETSI; Ethernet RJ45 PoE 4 antennas, 1x DI/DQ, 24 V DC; -25 to +55 °C; without accessories and antennas.

Siemens 6GT2811-7AD20-0AA0

Genuine, certified Siemens product
Fast sourcing through a worldwide supply network
Product selection and compatibility support from our technical team
Equivalent and alternative product suggestions
Quotation and lead time tailored to your request

Specifications

product brand nameSIMATIC RF

suitability for operationRFID high-performance reader for use in the warehouse environment for recording high flows of goods.

radio frequencies

operating frequency865 ... 868 MHz

transmit power3 ... 2000 mW

for each external antenna / maximum2000 mW

for each external antenna / maximum4000 mW

protocol / with radio transmissionEPCglobal Class 1 Gen 2 V2 / ISO/IEC 18000-62

transfer rate / with radio transmission / maximum640 kbit/s

product feature / multitag-capableYes

interfaces

number of external antennas4

standard for interfaces / for communicationEthernet, OPC UA, XML

for external antenna(s)RP-TNC

for supply voltageterminal block, 4-pole

at the digital inputs/outputsRJ45 connector (8-pole)

number of digital inputs1

number of digital outputs1

mechanical data

materialLexan

colorsilver, TI-Grey

mounting distance / relating to metal surfaces / recommended / minimum0 mm

supply voltage, current consumption, power loss

rated value24 V

20 ... 30 V

at 24 V / typical2 A

at 24 V / maximum2 A

ambient conditions

during operation-25 ... +55 °C

during storage-40 ... +85 °C

during transport-40 ... +85 °C

ambient condition / for operationWith operating temperature below -20 °C: Warming-up time at least 10 minutes

protection class IPIP33

shock resistanceEN 60068-2-27, EN 60068-2-6

shock acceleration250 m/s²

vibrational acceleration30 m/s²

resistance to mechanical stressThe maximum values for shock and vibration acceleration must not occur as continuous stress and they apply exclusively to assembly using screws

design, dimensions and weights

width245 mm

height209 mm

depth41 mm

net weight1.3 kg

fastening methodVesa 100 with 4 screws, DIN rail, mounting hole 4 x M4 screws

of antenna cable / minimum1 m

of antenna cable / maximum40 m

product features, product functions, product components / general

display version3 LEDs

protocol / is supported / Media Redundancy Protocol (MRP)No

product function / of the PROFINET IO device / is supported / H-Sync forwardingNo
