How can I get a price quote for Siemens 6GK1905-0EC00?

You can request a fast quote for Siemens 6GK1905-0EC00 from Yılsa Engineering. Reference part number CEY-8EF3B0301292. Submit a request via the contact or quote form and our team replies shortly with price and lead time.

Is Siemens 6GK1905-0EC00 in stock and what is the delivery time?

Yılsa Engineering sources products as genuine items through a wide supplier network. Typical lead time is 7-21 days, with 1-3 business days domestic transit in Türkiye. Current status is confirmed in the quote.

Is Siemens 6GK1905-0EC00 genuine and new?

Yes. This Siemens product is supplied genuine and brand-new, sold with invoice under Yılsa Engineering assurance.

How do I get the datasheet and technical specs for Siemens 6GK1905-0EC00?

Key technical specifications are listed on the product page. For the full datasheet, dimensions and compatibility, simply contact Yılsa Engineering.

Click to zoom

Photo may not represent actual item. Refer to name and product specs for all details.

Siemens 6GK1905-0EC00

M12 terminating connector for ET 200 with integrated terminating resistor combination for PB, Male contact insert, 1 pack=5 units.

SiemensMFR # 6GK1905-0EC00SKU # CEY-8EF3B0301292

product brand nameSIMATIC NET

transfer rate / with PROFIBUS9.6 kbit/s ... 12 Mbit/s

design of terminating resistorIntegrated resistor combination

material / of the enclosuremetal

locking mechanism designScrewed joint

type of cable outlet180° cable outlet

Have questions?Chat on WhatsApp

About This Product

M12 terminating connector for ET 200 with integrated terminating resistor combination for PB, Male contact insert, 1 pack=5 units.

Siemens 6GK1905-0EC00

Genuine, certified Siemens product
Fast sourcing through a worldwide supply network
Product selection and compatibility support from our technical team
Equivalent and alternative product suggestions
Quotation and lead time tailored to your request

Specifications

product brand nameSIMATIC NET

suitability for useAs terminating plug-in connector with integrated terminating resistors for ET200 PRO

transfer rate

transfer rate / with PROFIBUS9.6 kbit/s ... 12 Mbit/s

interfaces

for network components or terminal equipment1

for network components or terminal equipmentM12 connector (male insert, 4-pin, B-coded)

type of electrical connection / FastConnectNo

mechanical data

design of terminating resistorIntegrated resistor combination

material / of the enclosuremetal

locking mechanism designScrewed joint

tightening torque / for M12 round connector / maximum0.6 N·m

connector coding / of the M12 circular connectorB

design, dimensions and weights

type of cable outlet180° cable outlet

width19 mm

height19 mm

depth73 mm

net weight40 g

connectable cable diameter6 ... 8 mm

connectable conductor cross-section0.33 mm²

ambient conditions

during operation-40 ... +70 °C

during storage-40 ... +80 °C

during transport-40 ... +80 °C

to waterresistant

protection class IPIP65/67

product features, product functions, product components / general

silicon-freeYes

strain reliefYes

standards, specifications, approvals

RoHS conformityYes

UL approvalYes

railway application in accordance with EN 50155No
