Siemens 5ST3701-2HG

Pin busbar 1-phase, 1016 mm long touch-safe, 25 mm2 without end caps, according to UL 508

SiemensMFR # 5ST3701-2HGSKU # CEY-8EF3B0388FFC

product brand nameSENTRON

product designationPin busbar

design of the product37x 1PH

design of the phase tapL1/L1

compatibilityfor MCBs 1P or fuse holders 14 × 51 mm

design of pole1 pole

Have questions?Chat on WhatsApp

About This Product

Pin busbar 1-phase, 1016 mm long touch-safe, 25 mm2 without end caps, according to UL 508

Siemens 5ST3701-2HG

Genuine, certified Siemens product
Fast sourcing through a worldwide supply network
Product selection and compatibility support from our technical team
Equivalent and alternative product suggestions
Quotation and lead time tailored to your request

Specifications

product brand nameSENTRON

product designationPin busbar

design of the product37x 1PH

design of the phase tapL1/L1

General technical data

compatibilityfor MCBs 1P or fuse holders 14 × 51 mm

design of pole1 pole

phase number1

suitability for interaction devices with auxiliary switchNo

suitability for interaction devices with N conductorNo

colorlight grey

Product details

product component with end capNo

product feature attachable arc fault detection deviceNo

product feature insulatedYes

suitable for compact devicesNo

can be cutYes

number of devices suitable for fitting37

type of electrical connectionPin

Mechanical Design

module width18 mm

height5 mm

width15 mm

length1 000 mm

number of modular width units56

cross-section25 mm²

angle of the pin of busbar90°

Net Weight340 g

standards according to UL508
