Siemens 5SL3020-7KL

Photo may not represent actual item. Refer to name and product specs for all details.

Siemens 5SL3020-7KL

miniature circuit breaker 230 V, 4.5 kA, 1+N-pole/1 MW, N left, C20

SiemensMFR # 5SL3020-7KLSKU # YLSOOTWZVNPMXJY
product brand nameSENTRON
product designationMiniature circuit breaker
design of the productMiniature circuit breaker compact
design of pole1P+N
tripping characteristic classC
overvoltage category3
Share
Have questions?Chat on WhatsApp

About This Product

miniature circuit breaker 230 V, 4.5 kA, 1+N-pole/1 MW, N left, C20

Siemens 5SL3020-7KL

  • Genuine, certified Siemens product
  • Fast sourcing through a worldwide supply network
  • Product selection and compatibility support from our technical team
  • Equivalent and alternative product suggestions
  • Quotation and lead time tailored to your request

Specifications

Model
product brand nameSENTRON
product designationMiniature circuit breaker
design of the productMiniature circuit breaker compact
General technical data
design of pole1P+N
tripping characteristic classC
mechanical service life (operating cycles) typical10 000
overvoltage category3
degree of pollution2
Voltage
type of voltage of the operating voltageAC
insulation voltage (Ui) at AC rated value250 V
— at 30 °C rated value20 A
— at 40 °C rated value18.79 A
— at 50 °C rated value17.51 A
— at 55 °C rated value16.82 A
— at 60 °C rated value16.11 A
operational current at AC rated value20 A
Supply voltage
at AC230 V
at DC rated value60 V
value range of the supply voltage frequency50/60 Hz
minimum24 V
with single-phase operation at AC maximum250 V
Protection class
protection class IPIP20, with connected conductors
Breaking Capacity
according to EN 60898 rated value4.5 kA
energy limitation class3
Dissipation
at AC in hot operating state per pole2.2 W
Suitability
suitability for operationResidential buildings/infrastructure
Product details
product feature touch protectionYes
combined terminal topNo
combined terminal bottomNo
neutral conductor switchingYes
product feature properties for main switches in accordance with EN 60204-1No
product feature halogen-freeYes
product feature sealableYes
product feature silicon-freeYes
product extension installable supplementary devicesYes
Product function
communication functionNo
other measurement functionNo
Connections
minimum0.75 mm²
maximum16 mm²
minimum0.75 mm²
maximum16 mm²
minimum0.75 mm²
maximum10 mm²
minimum10.6 lbf·in
maximum22.1 lbf·in
minimum1.2 N·m
maximum2 N·m
position of power supply cordAny
Mechanical Design
height90 mm
width18 mm
depth76 mm
installation depth70 mm
number of modular width units1
fastening methodDIN rail
mounting positionany
Net Weight109 g
Environmental conditions
standardIEC/EN60898-1, GB/T10963.1
vibration resistance according to IEC 60068-2-6Yes
minimum-25 °C
maximum60 °C
ambient temperature during operation-25...45°C: max. 85%rF. 45...60°C: max. 43%rF
minimum-40 °C
maximum75 °C
number of test cycles for environmental testing according to IEC 60068-2-306
