How can I get a price quote for Siemens 5SK9102-1?

You can request a fast quote for Siemens 5SK9102-1 from Yılsa Engineering. Reference part number YLSA19YRWAYD2J. Submit a request via the contact or quote form and our team replies shortly with price and lead time.

Is Siemens 5SK9102-1 in stock and what is the delivery time?

Yılsa Engineering sources products as genuine items through a wide supplier network. Typical lead time is 7-21 days, with 1-3 business days domestic transit in Türkiye. Current status is confirmed in the quote.

Is Siemens 5SK9102-1 genuine and new?

Yes. This Siemens product is supplied genuine and brand-new, sold with invoice under Yılsa Engineering assurance.

How do I get the datasheet and technical specs for Siemens 5SK9102-1?

Key technical specifications are listed on the product page. For the full datasheet, dimensions and compatibility, simply contact Yılsa Engineering.

Click to zoom

Photo may not represent actual item. Refer to name and product specs for all details.

Siemens 5SK9102-1

circuit breaker Equipment elektronisch, 2A, DC 24V 1 auxilliary switch

SiemensMFR # 5SK9102-1SKU # YLSA19YRWAYD2J

product brand nameSENTRON

product designationDevice protection switch electronic

design of the productAssembly like a terminal

number of poles1

design of pole1P

overvoltage category3

Have questions?Chat on WhatsApp

About This Product

circuit breaker Equipment elektronisch, 2A, DC 24V 1 auxilliary switch

Siemens 5SK9102-1

Genuine, certified Siemens product
Fast sourcing through a worldwide supply network
Product selection and compatibility support from our technical team
Equivalent and alternative product suggestions
Quotation and lead time tailored to your request

Specifications

Model

product brand nameSENTRON

product designationDevice protection switch electronic

design of the productAssembly like a terminal

General technical data

number of poles1

design of pole1P

overvoltage category3

Voltage

type of voltage of the operating voltageDC

— at 40 °C rated value2 A

Supply voltage

at DC rated value24 V

operating voltage at DC rated value maximum30 V

Protection class

protection class IPIP20

suitability for operationInfrastructure / Industry

Product details

product feature touch protectionYes

neutral conductor switchingNo

product feature halogen-freeYes

product extension installable supplementary devicesNo

Connections

minimum0.2 mm²

maximum4 mm²

minimum0.2 mm²

maximum3 mm²

minimum0.2 mm²

maximum2.5 mm²

minimum24

maximum12

position of power supply cordAny

Mechanical Design

height105.8 mm

width6.2 mm

depth55.6 mm

installation depth56 mm

number of modular width units1

fastening methodStandard mounting rail TS 35

mounting positionany

Net Weight44 g

Environmental conditions

influence of the surrounding temperaturemax. 95% humidity

minimum-25 °C

maximum60 °C
