Photo may not represent actual item. Refer to name and product specs for all details.
Siemens 5SD610
DIAZED fuse link 750 V DC rail system protection Quick-response characteristic size DIII, E33, 50A
product brand nameSENTRON
product designationDIAZED fuse link
design of the productfor semiconductor protection
design of the fuse linkSILIZED fuse link, DIAZED design
tripping characteristic classquick-acting (F)
operating class of the fuse linkgG
About This Product
DIAZED fuse link 750 V DC rail system protection Quick-response characteristic size DIII, E33, 50A
Siemens 5SD610
- Genuine, certified Siemens product
- Fast sourcing through a worldwide supply network
- Product selection and compatibility support from our technical team
- Equivalent and alternative product suggestions
- Quotation and lead time tailored to your request
Specifications
Model
product brand nameSENTRON
product designationDIAZED fuse link
design of the productfor semiconductor protection
design of the fuse linkSILIZED fuse link, DIAZED design
General technical data
tripping characteristic classquick-acting (F)
size of fuse system according to EN 60269-1DIII
operating class of the fuse linkgG
Supply voltage
at AC750 V
at DC750 V
Protection class
protection class IPIP20, with connected conductors
Breaking Capacity
at AC according to IEC 60947-2 rated value50 kA
at DC according to IEC 60947-2 rated value8 kA
Dissipation
power loss [W]16.5 W
power loss [W] for rated value of the current at AC in hot operating state per pole16.5 W
Appearance
color coding of the fuse linkwhite
Product details
product descriptionUsing screw adapter or adapter sleeves
Mechanical Design
mounting positionAny, preferably vertical
Net Weight80 g
Environmental conditions
minimum-5 °C
maximum40 °C
environmental categoryUp to 45°C at 95 % rel. humidity
environmental category during storageair humidity 90% at 20°C
