Siemens 5SC211
DIAZED fuse link 500 V for cable and line protection gG, size DIVH, R1 1/4", 80A
product brand nameSENTRON
product designationDIAZED fuse link
design of the productFor cable and line protection
design of the fuse linkDIAZED fuse link
tripping characteristic classOther
operating class of the fuse linkgG
About This Product
DIAZED fuse link 500 V for cable and line protection gG, size DIVH, R1 1/4", 80A
Siemens 5SC211
- Genuine, certified Siemens product
- Fast sourcing through a worldwide supply network
- Product selection and compatibility support from our technical team
- Equivalent and alternative product suggestions
- Quotation and lead time tailored to your request
Specifications
Model
product brand nameSENTRON
product designationDIAZED fuse link
design of the productFor cable and line protection
design of the fuse linkDIAZED fuse link
General technical data
tripping characteristic classOther
size of fuse system according to EN 60269-1DIV
operating class of the fuse linkgG
Supply voltage
at AC500 V
at DC400 V
Protection class
protection class IPIP20, with connected conductors
Breaking Capacity
at AC according to IEC 60947-2 rated value50 kA
at DC according to IEC 60947-2 rated value8 kA
Dissipation
power loss [W]7.5 W
power loss [W] for rated value of the current at AC in hot operating state per pole7.5 W
Appearance
color coding of the fuse linksilver
Product details
product descriptionUsing screw adapter or adapter sleeves
Mechanical Design
mounting positionAny, preferably vertical
Net Weight115 g
Environmental conditions
minimum-5 °C
maximum40 °C
environmental categoryUp to 45°C at 95 % rel. humidity
environmental category during storageair humidity 90% at 20°C
