How can I get a price quote for Siemens 3VA9988-0AA21?

You can request a fast quote for Siemens 3VA9988-0AA21 from Yılsa Engineering. Reference part number CEY-8EF3B038A020. Submit a request via the contact or quote form and our team replies shortly with price and lead time.

Is Siemens 3VA9988-0AA21 in stock and what is the delivery time?

Yılsa Engineering sources products as genuine items through a wide supplier network. Typical lead time is 7-21 days, with 1-3 business days domestic transit in Türkiye. Current status is confirmed in the quote.

Is Siemens 3VA9988-0AA21 genuine and new?

Yes. This Siemens product is supplied genuine and brand-new, sold with invoice under Yılsa Engineering assurance.

How do I get the datasheet and technical specs for Siemens 3VA9988-0AA21?

Key technical specifications are listed on the product page. For the full datasheet, dimensions and compatibility, simply contact Yılsa Engineering.

Click to zoom

Photo may not represent actual item. Refer to name and product specs for all details.

Siemens 3VA9988-0AA21

leading changeover switch, changeover contacts type HP (14 mm) accessory for: 3VA11-15; 3VA20-26

SiemensMFR # 3VA9988-0AA21SKU # CEY-8EF3B038A020

product brand nameSENTRON

product designationLeading auxiliary switch

accessoriesLeading auxiliary switch

degree of pollution3

overvoltage categoryIII

lead time / relating to main contacts20 ms

Have questions?Chat on WhatsApp

About This Product

leading changeover switch, changeover contacts type HP (14 mm) accessory for: 3VA11-15; 3VA20-26

Siemens 3VA9988-0AA21

Genuine, certified Siemens product
Fast sourcing through a worldwide supply network
Product selection and compatibility support from our technical team
Equivalent and alternative product suggestions
Quotation and lead time tailored to your request

Specifications

Model

product brand nameSENTRON

product designationLeading auxiliary switch

accessoriesLeading auxiliary switch

General technical data

degree of pollution3

overvoltage categoryIII

lead time / relating to main contacts20 ms

Voltage

surge voltage resistance6 kV

operating voltage / at AC / at 50 Hz / rated value / minimum600 V

operating voltage / at DC / rated value / minimum250 V

Current

thermal current10 A

at AC-12 / at 12 V10 A

at AC-12 / at 24 V10 A

at AC-12 / at 48 V10 A

at AC-12 / at 125 V10 A

at AC-12 / at 220/240 V10 A

at AC-12 / at 380/400 V6 A

at AC-12 / at 400 V6 A

at AC-12 / at 600 V2 A

at DC-12 / at 12 V6 A

at DC-12 / at 24 V6 A

at DC-12 / at 48 V2 A

at DC-12 / at 110 V0.6 A

at DC-12 / at 250 V0.3 A

at DC-13 / at 12 V3 A

at DC-13 / at 24 V3 A

at DC-13 / at 48 V0.8 A

at DC-13 / at 110 V0.2 A

at DC-13 / at 250 V0.1 A

at AC-15 / at 12 V6 A

at AC-15 / at 24 V6 A

at AC-15 / at 48 V6 A

at AC-15 / at 125 V6 A

at AC-15 / at 220/240 V6 A

at AC-15 / at 380/400 V2 A

at AC-15 / at 600 V0.6 A

Mechanical Design

height56 mm

width14 mm

depth30 mm

Net Weight37 g

tightening torque / with screw-type terminals / minimum0.4 N·m

tightening torque / with screw-type terminals / maximum0.5 N·m

Connections according IEC

stripped length15 mm

maximum0.75 ... 2.5

minimum19

maximum14

Connetctions according UL

stripped length [in]0.6 in

tightening torque [lbf·in] / with screw-type terminals / minimum3.5 lbf·in

tightening torque [lbf·in] / with screw-type terminals / maximum4.4 lbf·in
