How can I get a price quote for Siemens 3VA9377-0TB50?

You can request a fast quote for Siemens 3VA9377-0TB50 from Yılsa Engineering. Reference part number YLSGBRBNSG6W9H. Submit a request via the contact or quote form and our team replies shortly with price and lead time.

Is Siemens 3VA9377-0TB50 in stock and what is the delivery time?

Yılsa Engineering sources products as genuine items through a wide supplier network. Typical lead time is 7-21 days, with 1-3 business days domestic transit in Türkiye. Current status is confirmed in the quote.

Is Siemens 3VA9377-0TB50 genuine and new?

Yes. This Siemens product is supplied genuine and brand-new, sold with invoice under Yılsa Engineering assurance.

How do I get the datasheet and technical specs for Siemens 3VA9377-0TB50?

Key technical specifications are listed on the product page. For the full datasheet, dimensions and compatibility, simply contact Yılsa Engineering.

Click to zoom

Photo may not represent actual item. Refer to name and product specs for all details.

Siemens 3VA9377-0TB50

24 V module accessory for: 3VA63 - 3VA66

SiemensMFR # 3VA9377-0TB50SKU # YLSGBRBNSG6W9H

product brand nameSENTRON

product designation24 V module

accessoriesCommunication and measurement function

suitability for operation3VA6 400/600

mounting positionRight switch pocket

degree of pollution3

Have questions?Chat on WhatsApp

About This Product

Siemens 3VA9377-0TB50 (24 V module accessory for: 3VA63 - 3VA66) is supplied genuine and fast by Yılsa Engineering. Get an instant quote for Siemens 3VA9377-0TB50 — price, stock availability and technical specifications.

Siemens 3VA9377-0TB50

Genuine, certified Siemens product
Fast sourcing through a worldwide supply network
Product selection and compatibility support from our technical team
Equivalent and alternative product suggestions
Quotation and lead time tailored to your request

Specifications

Model

product brand nameSENTRON

product designation24 V module

accessoriesCommunication and measurement function

General technical data

suitability for operation3VA6 400/600

mounting positionRight switch pocket

degree of pollution3

overvoltage categoryI

operating resource protection classIII (according to IEC 61558)

protection class IPIP20 according to IEC60529

Voltage

Rated control supply voltage Us with DC / maximal24 V

Current

electronic tripping unit power supplyYes

detection of switch position: On, Off, TrippedNo

communication with function moduleNo

communication with motor driveNo

communication with residual current equipmentNo

data exchange with the electronic tripping unitNo

power loss [W] / rated value2.4 W

control supply voltage / at DC / rated value / maximum24 V

relative symmetrical tolerance / of the operating range of the control feed voltage20 %

consumed current / maximum0.1 A

Mechanical Design

height63 mm

width29 mm

number of slots4

depth33 mm

Net Weight83 g

Connections

type of electrical connection / at the inputs for supply voltagescrew-type terminals

minimum0.5 mm²

maximum1.5 mm²

minimum0.5 mm²

maximum0.75 mm²

type of connectable conductor cross-sections / at the digital inputs / for AWG cables / solid20 to 16

tightening torque / with screw-type terminals / minimum0.22 N·m

tightening torque / with screw-type terminals / maximum0.25 N·m

Environmental conditions

minimum-25 °C

maximum70 °C

minimum-40 °C

maximum80 °C

minimum-40 °C

maximum80 °C
