How can I get a price quote for Siemens 3SE2902-0AA20?

You can request a fast quote for Siemens 3SE2902-0AA20 from Yılsa Engineering. Reference part number CEY-8EF3B032C751. Submit a request via the contact or quote form and our team replies shortly with price and lead time.

Is Siemens 3SE2902-0AA20 in stock and what is the delivery time?

Yılsa Engineering sources products as genuine items through a wide supplier network. Typical lead time is 7-21 days, with 1-3 business days domestic transit in Türkiye. Current status is confirmed in the quote.

Is Siemens 3SE2902-0AA20 genuine and new?

Yes. This Siemens product is supplied genuine and brand-new, sold with invoice under Yılsa Engineering assurance.

How do I get the datasheet and technical specs for Siemens 3SE2902-0AA20?

Key technical specifications are listed on the product page. For the full datasheet, dimensions and compatibility, simply contact Yılsa Engineering.

Click to zoom

Photo may not represent actual item. Refer to name and product specs for all details.

Siemens 3SE2902-0AA20

Old=3SE3902-0AA20 1-pedal With cover, without latching Metal enclosure IP65, 1 NO+1 NC, cable entry M20 x 1.5

SiemensMFR # 3SE2902-0AA20SKU # CEY-8EF3B032C751

product brand nameSIRIUS

product designationmomentary-contact foot switch

product type designation3SE29

protection class IPIP65

reference code according to IEC 81346-2S

Substance Prohibitance (day/month/year)07/01/2006

Have questions?Chat on WhatsApp

About This Product

Old=3SE3902-0AA20 1-pedal With cover, without latching Metal enclosure IP65, 1 NO+1 NC, cable entry M20 x 1.5

Siemens 3SE2902-0AA20

Genuine, certified Siemens product
Fast sourcing through a worldwide supply network
Product selection and compatibility support from our technical team
Equivalent and alternative product suggestions
Quotation and lead time tailored to your request

Specifications

product brand nameSIRIUS

product designationmomentary-contact foot switch

product type designation3SE29

General technical data

protection class IPIP65

mechanical service life (operating cycles) typical1 000 000

reference code according to IEC 81346-2S

Substance Prohibitance (day/month/year)07/01/2006

SVHC substance nameLead CAS-No. 7439-92-1

Net Weight1.399 kg

number of switching steps1

number of the actuation pedals1

minimum actuating force in directions of actuation15 N

Ambient conditions

ambient temperature during operation-25 ... +80 °C

number of NC contacts for auxiliary contacts1

number of NO contacts for auxiliary contacts1

at 230 V rated value16 A

at 400 V rated value16 A

at 24 V rated value3 A

at 250 V rated value0.25 A

Enclosure

material of the enclosuremetal

of the enclosureblack

of the enclosure top partgrey

Actuator

interlockNo

latchingNo

cable entry typeM20 x 1.5

Installation/ mounting/ dimensions

height138 mm

width156 mm

depth265 mm

Safety related data

with low demand rate according to SN 3192050 %

with high demand rate according to SN 3192050 %

B10 value with high demand rate according to SN 319201 000 000

failure rate [FIT] with low demand rate according to SN 31920100 FIT

IEC 61508

T1 value for proof test interval or service life according to IEC 6150820 a
