Photo may not represent actual item. Refer to name and product specs for all details.

Siemens 3NB1223-3KK15

SITOR fuse size 2 100A aR 1000V dc/1250V VSI 1100V dc UL @MBC 7xIn screw connection M10 170mm slotted knives

SiemensMFR # 3NB1223-3KK15SKU # YLS7KTFIO3VGP2S

product brand nameSENTRON

product designationSITOR fuse link

design of the productWith slotted blade contacts

design of an identification indicatorWithout indicator

design of the switching contactM10 170 mm slotted blades

design of the fuse linkSITOR, LV HRC design

Have questions?Chat on WhatsApp

About This Product

SITOR fuse size 2 100A aR 1000V dc/1250V VSI 1100V dc UL @MBC 7xIn screw connection M10 170mm slotted knives

Siemens 3NB1223-3KK15

Genuine, certified Siemens product
Fast sourcing through a worldwide supply network
Product selection and compatibility support from our technical team
Equivalent and alternative product suggestions
Quotation and lead time tailored to your request

Specifications

Model

product brand nameSENTRON

product designationSITOR fuse link

design of the productWith slotted blade contacts

design of an identification indicatorWithout indicator

design of the switching contactM10 170 mm slotted blades

design of the fuse linkSITOR, LV HRC design

General technical data

size of fuse system according to EN 60269-1NH2

operating class of the fuse linkaR

type of voltage of the operating voltageDC

Supply voltage

at DC1 000 V

Breaking Capacity

at DC according to IEC 60947-2 rated value100 kA

according to IEC 60947-2 rated value100 kA

Dissipation

power loss [W]45 W

for rated value of the current at AC in hot operating state per pole45 W

maximum45 W

Product details

product descriptionwith slotted blade contacts, silver-plated

accessories includedno

Mechanical Design

mounting positionAny, preferably vertical

Net Weight1.362 kg

Environmental conditions

minimum-20 °C

maximum50 °C

environmental category-20 to +50 at 95% relative humidity

Accessories 5

Genuine accessories that can be used with the Siemens 3NB1223-3KK15 motor and are supplied separately are listed below. Click a code to open the accessory page and see the other compatible motors.

Part no	Description	Compatible motors
3NH1330	Uyumlu ürün · LV HRC fuse system
3NH2330	Uyumlu ürün · LV HRC fuse system
3NH6320	Uyumlu ürün · LV HRC fuse system
3NH6330	Uyumlu ürün · LV HRC fuse system
3NH5463	Seçmeli zorunlu ürün · LV HRC fuse system
