How can I get a price quote for Festo YHBP-?

You can request a fast quote for Festo YHBP- from Yılsa Engineering. Reference part number YLS8IIZFHMWN0Q9. Submit a request via the contact or quote form and our team replies shortly with price and lead time.

Is Festo YHBP- in stock and what is the delivery time?

Yılsa Engineering sources products as genuine items through a wide supplier network. Typical lead time is 7-21 days, with 1-3 business days domestic transit in Türkiye. Current status is confirmed in the quote.

Is Festo YHBP- genuine and new?

Yes. This Festo product is supplied genuine and brand-new, sold with invoice under Yılsa Engineering assurance.

How do I get the datasheet and technical specs for Festo YHBP-?

Key technical specifications are listed on the product page. For the full datasheet, dimensions and compatibility, simply contact Yılsa Engineering.

Click to zoom

Photo may not represent actual item. Refer to name and product specs for all details.

Festo YHBP-

Balancer kit. Very low operating forces of just 10 N. For applications involving the movement of heavy loads in defined, repetitive sequences. Extremely fast, automatic weight detection for a wide range of variants in production processes. With safety functions. The individual components are delivered mounted in the control cabinet, on a mounting plate or unassembled

FestoMFR # YHBP-SKU # YLS8IIZFHMWN0Q9

Stroke range100, 1990

Cylinder diameter50, 200

Supported kinematicLifting column, Parallel kinematics

Reverse polarity protectionFor operating voltage

Operating pressure0.4, 0.8

Operating pressure4, 8

Have questions?Chat on WhatsApp

About This Product

Festo YHBP-

Genuine, certified Festo product
Fast sourcing through a worldwide supply network
Product selection and compatibility support from our technical team
Equivalent and alternative product suggestions
Quotation and lead time tailored to your request

Specifications

Stroke range100, 1990

Cylinder diameter50, 200

Supported kinematicLifting column, Parallel kinematics

Reverse polarity protectionFor operating voltage

Operating pressure0.4, 0.8

Operating pressure4, 8

Max. travel speed1

Operational voltage range DC21.6, 26.4

Duty cycle100%

Nominal operating voltage DC24

Residual ripple5%

Current consumption with no-load outputs2000

Operating mediumCompressed air to ISO 8573-1:2010 [6:4:4]

LABS (PWIS) conformityVDMA24364 zone III

Storage temperature-20, 70

Degree of protectionIP65

Note on degree of protectionIn mounted state, IP20 for controller CECC

Ambient temperature0, 50

Load25, 999

Transmission ratio of kinematics1:5 for lifting columns, 1:1 - 1:5 for parallel kinematics system

Product weight4800, 60500

Note on materialsRoHS compliant

Accessories 27

Genuine accessories that can be used with the Festo YHBP- motor and are supplied separately are listed below. Click a code to open the accessory page and see the other compatible motors.

Part no	Description	Compatible motors
SG-M20X1,5	Rod clevis · Piston rod attachments
SGS-M10X1,25	Rod eye · Piston rod attachments
SG-M36X2	Rod clevis · Piston rod attachments
SG-M27X2-B	Rod clevis · Piston rod attachments
IBS-6X10	Inscription label · General accessories
HNG-160	Foot mounting · Cylinder mountings
HNG-200	Foot mounting · Cylinder mountings
SNGB-160	Swivel flange · Cylinder mountings
SNGL-160	Swivel flange · Cylinder mountings
SNGL-200	Swivel flange · Cylinder mountings
HNC-32	Foot mounting · Cylinder mountings
HNC-80	Foot mounting · Cylinder mountings
HNC-100	Foot mounting · Cylinder mountings
HNC-125	Foot mounting · Cylinder mountings
SNC-32	Swivel flange · Cylinder mountings
SNCB-80	Swivel flange · Cylinder mountings
SNCB-100	Swivel flange · Cylinder mountings
SNCB-125	Swivel flange · Cylinder mountings
SNCS-32	Swivel flange · Cylinder mountings
SNCL-80	Swivel flange · Cylinder mountings
SNCL-100	Swivel flange · Cylinder mountings
SNCL-125	Swivel flange · Cylinder mountings
SNCB-80-R3	Swivel flange · Cylinder mountings
SNCB-100-R3	Swivel flange · Cylinder mountings
SNCB-125-R3	Swivel flange · Cylinder mountings
SNGB-200-B	Swivel flange · Cylinder mountings
NEBC-M12G5-ES-5-LE5-CO	Connecting cable · Connecting cables
