Festo VZQH-

Pinch valve. Manually operated 2/2-way valve for liquids, dusty media, solids and mixtures. Closed at a lever position of 90°, secured by locking the blue safety element. Automatic return to the closed position (NC) by spring force when the hand lever is released. Can be latched every 15° via the blue safety element for an even media flow. Can be secured against unintentional actuation. Suitable for direct contact with food according to European Regulation (EC) No. 1935/2004

FestoMFR # VZQH-SKU # YLSLPG88BO9SO2

DesignPinch valve

Type of actuationManual

Sealing principleSoft

Mounting positionAny

Type of mountingInline installation

Nominal size DN6

Have questions?Chat on WhatsApp

About This Product

Festo VZQH-

Genuine, certified Festo product
Fast sourcing through a worldwide supply network
Product selection and compatibility support from our technical team
Equivalent and alternative product suggestions
Quotation and lead time tailored to your request

Specifications

DesignPinch valve

Type of actuationManual

Sealing principleSoft

Mounting positionAny

Type of mountingInline installation

Connection Process valveClamp according to ASME-BPE Type A, Clamp to DIN 32676 series A, G1/4, 1/4 NPT

Nominal size DN6

Valve function2/2-way, single solenoid, closed

Flow directionReversible

Medium pressure0, 0.6

Medium pressure0, 6

Medium pressure0, 87

Nominal pressure PN10

Burst pressure1.6

Burst pressure16

Burst pressure232

Type of resetMechanical spring

Type of pilotingDirect

Symbol00992981

MediumCompressed air to ISO 8573-1:2010 [-:-:1], Water

Max. viscosity4000

Media temperature-5, 100

Ambient temperature-5, 60

Storage temperature5, 30

Flow rate Kv0.7

Switching time on1000

Switching time off1000

Note on materialsRoHS compliant

LABS (PWIS) conformityVDMA24364 zone III

Material housingHigh-alloy stainless steel

Material number housing1,4408

Material housing coverHigh-alloy stainless steel

Material number housing cover1.4404 / AISI 316L

Material sealsFluoro rubber, HNBR

Material shut-off elementEPDM, VMQ (silicone)

Product weight370, 427

Suitable for use with foodSee supplementary material information
