How can I get a price quote for Festo VAD-1/4?

You can request a fast quote for Festo VAD-1/4 from Yılsa Engineering. Reference part number CEY-937FC7826CC2. Submit a request via the contact or quote form and our team replies shortly with price and lead time.

Is Festo VAD-1/4 in stock and what is the delivery time?

Yılsa Engineering sources products as genuine items through a wide supplier network. Typical lead time is 7-21 days, with 1-3 business days domestic transit in Türkiye. Current status is confirmed in the quote.

Is Festo VAD-1/4 genuine and new?

Yes. This Festo product is supplied genuine and brand-new, sold with invoice under Yılsa Engineering assurance.

How do I get the datasheet and technical specs for Festo VAD-1/4?

Key technical specifications are listed on the product page. For the full datasheet, dimensions and compatibility, simply contact Yılsa Engineering.

Click to zoom

Photo may not represent actual item. Refer to name and product specs for all details.

Festo VAD-1/4

Vacuum generator. Sturdy aluminium housing for direct connection of a suction cup

FestoMFR # VAD-1/4SKU # CEY-937FC7826CC2

Nominal size, Laval nozzle1

Mounting positionAny

Ejector characteristicHigh vacuum

DesignT-shape

Symbol00991482

Operating pressure0.15, 1

Have questions?Chat on WhatsApp

About This Product

Vacuum generator. Sturdy aluminium housing for direct connection of a suction cup

Festo VAD-1/4

Genuine, certified Festo product
Fast sourcing through a worldwide supply network
Product selection and compatibility support from our technical team
Equivalent and alternative product suggestions
Quotation and lead time tailored to your request

Specifications

Nominal size, Laval nozzle1

Mounting positionAny

Ejector characteristicHigh vacuum

DesignT-shape

Symbol00991482

Operating pressure0.15, 1

Operating pressure1.5, 10

Operating pressure21.75, 145

Max. vacuum80

Operating mediumCompressed air to ISO 8573-1:2010 [7:4:4]

Note on operating and pilot mediumLubricated operation possible (in which case lubricated operation will always be required)

LABS (PWIS) conformityVDMA24364-B1/B2-L

Media temperature-20, 80

Ambient temperature-20, 80

Type of mountingWith through-hole

Pneumatic connection, port 1G1/4

Pneumatic connection, port 3G1/4

Vacuum connectionG1/4

Material housingDie-cast aluminium

Accessories 52

Genuine accessories that can be used with the Festo VAD-1/4 motor and are supplied separately are listed below. Click a code to open the accessory page and see the other compatible motors.

Part no	Description	Compatible motors
PUN-H-10X1,5-TBL	Plastic tubing · Tubes
PUN-H-10X1,5-BL	Plastic tubing · Tubes
PUN-H-10X1,5-SW	Plastic tubing · Tubes
VAS-40-1/4-PUR-B	Suction cup with connection · General accessories
PUN-H-10X1,5-NT	Plastic tubing · Tubes
QSL-G1/4-10	Push-in L-fitting · Fittings
QS-G1/4-10	Push-in fitting · Fittings
QS-G1/4-10-I	Push-in fitting · Fittings
U-1/4	Silencer · Silencer
CK-1/4-PK-4	Quick connector · Quick connectors
CK-1/4-PK-6	Quick connector · Quick connectors
CK-1/4-PK-9	Quick connector · Quick connectors
CK-1/4-PK-4-KU	Quick connector · Quick connectors
CK-1/4-PK-6-KU	Quick connector · Quick connectors
CK-1/4-PK-9-KU	Quick connector · Quick connectors
U-1/4-B	Silencer · Silencer
CN-1/4-PK-4	Barbed fitting · Barbed fittings
CN-1/4-PK-6	Barbed fitting · Barbed fittings
CRCN-1/4-PK-4	Barbed fitting · Stainless-steel fittings
CRCN-1/4-PK-6	Barbed fitting · Stainless-steel fittings
VAF-PK-4	Vacuum filter · General accessories
QS-1/4-8-50	Push-in fitting · Push-in fittings
QS-1/4-10-50	Push-in fitting · Push-in fittings
QS-G1/4-8-50	Push-in fitting · Push-in fittings
QS-G1/4-10-50	Push-in fitting · Push-in fittings
CRQS-1/4-8-I	Push-in fitting · Stainless-steel fittings
CRQS-1/4-10-I	Push-in fitting · Stainless-steel fittings
QS-1/4-10-I-50	Push-in fitting · Push-in fittings
QS-1/4-8-I-50	Push-in fitting · Push-in fittings
QS-1/4-8	Push-in fitting · Push-in fittings
QS-1/4-10	Push-in fitting · Push-in fittings
QS-1/4-8-I	Push-in fitting · Push-in fittings
QS-1/4-10-I	Push-in fitting · Push-in fittings
VAF-PK-6	Vacuum filter · General accessories
QS-V0-1/4-8	Push-in fitting · Push-in fittings
QS-V0-1/4-10	Push-in fitting · Push-in fittings
CRQS-1/4-8	Push-in fitting · Stainless-steel fittings
CRQS-1/4-10	Push-in fitting · Stainless-steel fittings
UC-1/4	Silencer · Silencer
QS-G1/4-8	Push-in fitting · Push-in fittings
QS-G1/4-8-I	Push-in fitting · Push-in fittings
QS-V0-G1/4-8	Push-in fitting · Push-in fittings
QS-V0-G1/4-10	Push-in fitting · Push-in fittings
UO-1/4	Silencer · Silencer
UC-1/4-20	Silencer · Silencer
U-1/4-20	Silencer · Silencer
VAF-PK-3	Vacuum filter · General accessories
VAF-DB-1/4	Vacuum filter · General accessories
VAF-DB-3/8	Vacuum filter · General accessories
VAF-DB-1/2	Vacuum filter · General accessories
AMTE-M-LH-G14	Silencer · Silencer
AMTE-M-H-G14	Silencer · Silencer
