Festo CDPX-X-B-W-10
Operator unit. Cost-optimised for simple visualisation tasks, e.g. of process data. Powerful processors combined with wide-screen technology. Ideally matched to CODESYS controls from Festo or ModbusTCP networks. Integrated EtherNet interfaces. With touchscreen. Variants according to EU explosion protection directive (ATEX) and in IP67 suitable for the requirements in process automation
Width282
Mounting depth29
Height197
Length34
Max. front panel thickness5
Real-time clockYes
About This Product
Operator unit. Cost-optimised for simple visualisation tasks, e.g. of process data. Powerful processors combined with wide-screen technology. Ideally matched to CODESYS controls from Festo or ModbusTCP networks. Integrated EtherNet interfaces. With touchscreen. Variants according to EU explosion protection directive (ATEX) and in IP67 suitable for the requirements in process automation
Festo CDPX-X-B-W-10
- Genuine, certified Festo product
- Fast sourcing through a worldwide supply network
- Product selection and compatibility support from our technical team
- Equivalent and alternative product suggestions
- Quotation and lead time tailored to your request
Specifications
Width282
Mounting depth29
Height197
Length34
Max. front panel thickness5
Real-time clockYes
Deviation, real-time clock< 100 ppm at 25 °C
Number of colours64 k
DisplayWith backlighting
Display typeTFT colour
Display characteristicsTouchscreen
Display size10.1"
Backup batterySuper capacitor
Operational voltage range DC10, 32
Display resolution1024x600 pixels
Nominal operating voltage DC24
Current consumption at nominal operating voltage0.38 A
Approvalc UL us - Listed (Oil)
CE mark (see declaration of conformity)To EU EMC Directive, In accordance with EU RoHS Directive
UKCA marking (see declaration of conformity)To UK RoHS instructions
LABS (PWIS) conformityVDMA24364 zone III
Storage temperature-20, 70
Relative air humidity5 - 85%, Non-condensing
Degree of protectionIP20, IP66
Note on degree of protectionIP66 front
Ambient temperature0, 50
Note on ambient temperatureFor vertical mounting
Product weight1000
Additional functionsRS232 communication function
Type of mountingFront panel mounting
Note on materialsRoHS compliant
Ethernet interface, connection typeSocket
Ethernet interface, connection systemRJ45
Ethernet interface, number of pins/wires8
Ethernet interface, transmission rate10/100 Mbit/s
Ethernet interface, functionProgramming
USB interface, functionFile transfer
USB interface, type of connectionSocket
USB interface, connection technologyUSB 2.0 type A
Programming softwareDesigner Studio
CPU data512 MB RAM
Related Products
View Details
Festo
CDPX-X-E1-W-10
MFR #CDPX-X-E1-W-10
SKU #YLS3OLCLCZNHW0
View Details
Festo
CDPX-X-E2-W-10-EX2
MFR #CDPX-X-E2-W-10-EX2
SKU #YLSIA5BCDESMR6Y
View Details
Festo
CDPX-X-E1-W-15
MFR #CDPX-X-E1-W-15
SKU #YLSHT91ORMXGVJ
View Details
Festo
CDPX-X-E2-W-15-EX2
MFR #CDPX-X-E2-W-15-EX2
SKU #YLSN3ZWTKAKMAFV
View Details
Festo
CDPX-X-B-W-4
MFR #CDPX-X-B-W-4
SKU #YLSVHFKN32XQU2K
View Details
Festo
CDPX-X-E2-W-5-EX2
MFR #CDPX-X-E2-W-5-EX2
SKU #YLSPKTKCOGXDGKK
View Details
Festo
CDPX-X-B-W-7
MFR #CDPX-X-B-W-7
SKU #YLS2AAMUNFILGWD
View Details
Festo
CDPX-X-E1-W-7
MFR #CDPX-X-E1-W-7
SKU #YLSCNUOX1BO2KD5
View Details
Festo
CDSV-P20-A
