How can I get a price quote for Enerpac ZU4308RB?

You can request a fast quote for Enerpac ZU4308RB from Yılsa Engineering. Reference part number YLSY2IJ6TD7C9AZ. Submit a request via the contact or quote form and our team replies shortly with price and lead time.

Is Enerpac ZU4308RB in stock and what is the delivery time?

Yılsa Engineering sources products as genuine items through a wide supplier network. Typical lead time is 7-21 days, with 1-3 business days domestic transit in Türkiye. Current status is confirmed in the quote.

Is Enerpac ZU4308RB genuine and new?

Yes. This Enerpac product is supplied genuine and brand-new, sold with invoice under Yılsa Engineering assurance.

How do I get the datasheet and technical specs for Enerpac ZU4308RB?

Key technical specifications are listed on the product page. For the full datasheet, dimensions and compatibility, simply contact Yılsa Engineering.

Click to zoom

Photo may not represent actual item. Refer to name and product specs for all details.

Enerpac ZU4308RB 700 bar Electric Hydraulic Pump

Enerpac ZU4308RB; 700 bar (10,000 psi), 2 gal (≈7.6 L) usable oil, 1.7 hp, 115V portable electric hydraulic pump with manual 3/3 valve (Classic).

EnerpacMFR # ZU4308RBSKU # YLSY2IJ6TD7C9AZ

Maximum Operating Pressure Range10,000 psi

Motor Phases1 Ph

Dimension D206 mm (8.1 in)

Maximum Flow at Rated Pressure60 in3/min

Dimension C279 mm (11 in)

Motor Electrical Specification115 V, 1 Ph, 50/60 Hz

Have questions?Chat on WhatsApp

About This Product

ZU4308RB is a portable electric hydraulic pump from the Classic class of the ZU series, running on 115 V, 1 phase, 50/60 Hz. Maximum operating pressure is 700 bar (10,000 psi) and usable oil capacity is 2 gal (≈7.6 L), with a 416 in³ reservoir. Motor power is 1.7 hp. The pump has a manual 3-way, 3-position, tandem-center valve (advance / hold / retract). Relief valve range is 140-700 bar and maximum flow at rated pressure is 60 in³/min (≈1.0 l/min). It is designed for intermittent duty and is used to power cylinders or hydraulic tools.

Features and Benefits

Patented Z-Class pump technology: high by-pass pressure for productivity with long hose runs and high pressure-drop circuits
18% less current draw than comparable pumps and cooler running
1.7 hp universal motor with high power-to-weight ratio and good low-voltage operation
Manual 3-way, 3-position tandem-center valve (advance / hold / retract)
700 bar maximum pressure with 140-700 bar adjustable relief valve

Enerpac ZU4308RB

Genuine, certified Enerpac product
Fast sourcing through a worldwide supply network
Product selection and compatibility support from our technical team
Equivalent and alternative product suggestions
Quotation and lead time tailored to your request

Specifications

Maximum Operating Pressure Range10,000 psi

Motor Phases1 Ph

Dimension D206 mm (8.1 in)

Maximum Flow at Rated Pressure60 in3/min

Dimension C279 mm (11 in)

Motor Electrical Specification115 V, 1 Ph, 50/60 Hz

Output Flow Rate @ 50 bar8,8 l/min

Valve FunctionAdvance / Hold / Retract

Dimension B142 mm (5.6 in)

Motor Voltage115 V V

Usable Oil Capacity8,0 l (2 gal)

Pump ControlManual

Output Flow Rate (100 psi)700 in³/min

Relief Valve Adjustment Range140 - 700 bar (2,000 - 10,000 psi)

Motor Frequency50/60 Hz Hz

Product TypeElectric Pump - Portable

Duty CycleIntermittent

Reservoir Capacity8000 cm³ (416 in³)

Sound Level85 - 90 dB(A)

Maximum Operating Pressure10,000 psi

Valve OperationManual

Pump Valve Type3-way, 3-position, Tandem Center

Output Flow Rate @ 7 bar11,5 l/min

Motor Size1.7 hp

SeriesZU

Output Flow Rate @ 700 bar1,0 l/min (60 in³/min)

Pump Power SourceElectric

Flow Rate Range at Rated Pressure60 - 119 in³/min

Output Flow Rate (700 psi)535 in³/min

Cylinder CompatibilitySingle-acting

Output Flow Rate (5000 psi)76 in³/min

Dimension A424 mm (16.7 in)

Valve ModelVM33

Product LineIndustrial Tools

Weight32 kg (70 lbs)

Output Flow Rate @ 350 bar1,2 l/min

Documents & CAD

Series documents 5· shared by this product series

Instruction ManualElectric Pump, Foundation Repair & Post TensioningPDF·4.0 MB 4 languages· in one file

Repair Parts SheetOil Filter KitPDF·387 KB·English

Repair Parts SheetRepair Parts SheetPDF·3.0 MB 4 languages· in one file

Repair Parts SheetZU4 Electric Pump Tensioning and Foundation RepairPDF·1.7 MB 4 languages· in one file

BrochureZU4-Series Electric Pumps; EnglishPDF·766 KB
