How can I get a price quote for Enerpac WAP15008D?

You can request a fast quote for Enerpac WAP15008D from Yılsa Engineering. Reference part number YLSPYLLKVH01II. Submit a request via the contact or quote form and our team replies shortly with price and lead time.

Is Enerpac WAP15008D in stock and what is the delivery time?

Yılsa Engineering sources products as genuine items through a wide supplier network. Typical lead time is 7-21 days, with 1-3 business days domestic transit in Türkiye. Current status is confirmed in the quote.

Is Enerpac WAP15008D genuine and new?

Yes. This Enerpac product is supplied genuine and brand-new, sold with invoice under Yılsa Engineering assurance.

How do I get the datasheet and technical specs for Enerpac WAP15008D?

Key technical specifications are listed on the product page. For the full datasheet, dimensions and compatibility, simply contact Yılsa Engineering.

Click to zoom

Photo may not represent actual item. Refer to name and product specs for all details.

Enerpac WAP15008D 190 bar Air Hydraulic Pump

Enerpac WAP15008D; 465 in³/min (≈7.6 L/min) flow, 190 bar (2,760 psi) max pressure, 23:1 ratio air-driven hydraulic pump, 415 in³ (≈6.8 L) usable oil.

EnerpacMFR # WAP15008DSKU # YLSPYLLKVH01II

Maximum Operating Pressure Range< 5,000 psi

Country of OriginChina

Maximum Flow at Rated Pressure465 in3/min (465 in³/min)

Output Flow Rate at No Load465 in³/min

Air Pressure Range30 - 120 psi

Hydraulic to Air Ratio23:1

Have questions?Chat on WhatsApp

About This Product

WAP15008D is an air-driven hydraulic pump from the Enerpac WAP series in the workholding product line. It provides industrial, high-cycle, high-flow hydraulic supply. The hydraulic-to-air ratio is 23:1, with 465 in³/min (≈7.6 L/min) flow at 0 psi. Max hydraulic pressure is 2,760 psi (≈190 bar) at 120 psi air and 2,320 psi (≈160 bar) at 100 psi (≈6.9 bar) air. Air pressure range is 30–120 psi, air consumption 24 scfm, reservoir 1.8 gal (415 in³ usable oil), relief valve setting 3,000 psi. Weight is 71 lb (≈32 kg). It features heavy-duty construction with a steel reservoir and protective steel shroud, and comes with a standard four-station DO3 manifold. It suits workholding systems and machine tool hydraulics.

Features and Benefits

Industrial, high-cycle, high-flow hydraulic supply
Heavy-duty construction with steel reservoir and protective steel shroud
Long-life, fully serviceable air motor; requires no air lubrication
On-demand stall/restart operation automatically maintains system pressure
Adjustable hydraulic pressure via built-in air filter/regulator
Reduced noise level (75 dBA) and standard four-station DO3 manifold

Enerpac WAP15008D

Genuine, certified Enerpac product
Fast sourcing through a worldwide supply network
Product selection and compatibility support from our technical team
Equivalent and alternative product suggestions
Quotation and lead time tailored to your request

Specifications

Maximum Operating Pressure Range< 5,000 psi

Country of OriginChina

Maximum Flow at Rated Pressure465 in3/min (465 in³/min)

Output Flow Rate at No Load465 in³/min

Air Pressure Range30 - 120 psi

Hydraulic to Air Ratio23:1

Reservoir Capacity1.8 gal

Product TypeAir Pump

Reservoir Capacity415 in³

Maximum Operating Pressure2,760 psi

SeriesWAP

Max. Hydraulic Pressure (100%)2320 psi

Usable Oil Capacity415 in³

Pump Power SourceAir

Flow Rate Range at Rated Pressure> 200 in³/min

Air Consumption24 scfm

Product LineWorkholding Tools

Weight71 lbs

Relief Valve Adjustment Range3000 psi

Documents & CAD

Series documents 6· shared by this product series

Instruction ManualDuroTech Series Air-Driven Hydraulic PumpPDF·3.0 MB·English

Repair Parts SheetWAP Series Air Pump (DuroTech™ )PDF·4.8 MB·English

CertificateL4895_a_EN_AUPDF·280 KB

CertificateHF_Oil_Safety_Data_Sheet_for_HF102L_HF104L_and_HF105L_Oil_EN-AUPDF·182 KB·English

BrochureWAP_Air_Driven_Power_Units_Duro-Tech-SeriesPDF·347 KB·English

DocumentPump Element Seal ReplacementPDF·4.4 MB·English

CAD Files 3

3D Model
