How can I get a price quote for Enerpac RLN502?

You can request a fast quote for Enerpac RLN502 from Yılsa Engineering. Reference part number YLSRHEQIHYKQ3YY. Submit a request via the contact or quote form and our team replies shortly with price and lead time.

Is Enerpac RLN502 in stock and what is the delivery time?

Yılsa Engineering sources products as genuine items through a wide supplier network. Typical lead time is 7-21 days, with 1-3 business days domestic transit in Türkiye. Current status is confirmed in the quote.

Is Enerpac RLN502 genuine and new?

Yes. This Enerpac product is supplied genuine and brand-new, sold with invoice under Yılsa Engineering assurance.

How do I get the datasheet and technical specs for Enerpac RLN502?

Key technical specifications are listed on the product page. For the full datasheet, dimensions and compatibility, simply contact Yılsa Engineering.

Click to zoom

Photo may not represent actual item. Refer to name and product specs for all details.

Enerpac RLN502 50 ton Locknut Cylinder

Enerpac RLN502; 50 ton (444.8 kN) capacity, 50.8 mm (2 in) stroke, 700 bar (10,000 psi), single-acting steel locknut hydraulic cylinder.

EnerpacMFR # RLN502SKU # YLSRHEQIHYKQ3YY

Required Oil Capacity362,2 cm³ (22.1 in³)

Ram Bore Diameter95,3 mm (3.75 in)

Maximum Operating Pressure700 bar (10,000 psi)

Product TypeLocknut Cylinder

SeriesRLN - discontinued

Pressure at Capacity624 bar (9054 psi)

Have questions?Chat on WhatsApp

About This Product

The RLN502 is a single-acting steel locknut hydraulic cylinder with 50 ton (444.8 kN) capacity and 50.8 mm (2 in) stroke. Maximum operating pressure is 700 bar (10,000 psi) and it has a solid plunger. The locknut provides extended load holding. It features a stop ring against piston blow-out and a Class 2 ACME thread. 5-degree swivel load caps on 30-100 ton models provide side-load protection. Dimensions: ram bore 95.3 mm, body outside diameter 127 mm, collapsed height 171.5 mm, extended height 222.3 mm, oil capacity 362.2 cm³, effective area 71.3 cm², weight approx. 17 kg (38 lb). Country of origin: United States. It is used for short-stroke lifting and load holding.

Features and Benefits

50 ton (444.8 kN) capacity, 50.8 mm (2 in) stroke
Locknut for extended load holding
Stop ring for piston blow-out protection
5-degree swivel load cap for side-load protection
Class 2 ACME thread: high strength and easy locknut positioning
Compact: collapsed height 171.5 mm, weight approx. 17 kg

Enerpac RLN502

Genuine, certified Enerpac product
Fast sourcing through a worldwide supply network
Product selection and compatibility support from our technical team
Equivalent and alternative product suggestions
Quotation and lead time tailored to your request

Specifications

Required Oil Capacity362,2 cm³ (22.1 in³)

Ram Bore Diameter95,3 mm (3.75 in)

Maximum Operating Pressure700 bar (10,000 psi)

Product TypeLocknut Cylinder

SeriesRLN - discontinued

Pressure at Capacity624 bar (9054 psi)

Product LineHydraulic Tools

Weight17,2 kg (38.0 lbs)

Cylinder Class50 ton

Country of OriginUnited States

Base to Port Centerline (E)19,8 mm (0.78 in)

Body Outside Diameter (C)127 mm (5 in)

Cylinder Effective Area71,3 cm² (11.05 in²)

Extended Height (B)222,3 mm (8.75 in)

Capacity444,8 kN (50 ton)

Plunger TypeSolid

Collapsed Height (A)171.5 mm (6.75 in)

Cylinder MaterialSteel

Piston Outside Diameter (D)81 mm (3.19 in)

Stroke50.8 mm (2.00 in)

Return TypeSingle-Acting, Load Return
