Enerpac RLN100012 1000 ton Locknut Cylinder

Enerpac RLN100012; 1000 ton (8896.4 kN) capacity, 304.8 mm (12 in) stroke, 700 bar maximum pressure, single-acting steel locknut hydraulic cylinder.

EnerpacMFR # RLN100012SKU # YLSCAH0SVPYYH0

Required Oil Capacity39525,6 cm³ (2412.0 in³)

Ram Bore Diameter406,4 mm (16 in)

Maximum Operating Pressure700 bar (10,000 psi)

Product TypeLocknut Cylinder

SeriesRLN - discontinued

Pressure at Capacity686 bar (9950 psi)

Have questions?Chat on WhatsApp

About This Product

RLN100012 is a 1000 ton (8896.4 kN), 304.8 mm (12 in) stroke, single-acting steel locknut hydraulic cylinder. Its series is listed as RLN (discontinued). Maximum operating pressure is 700 bar (10,000 psi). The piston outside diameter is 376.2 mm, ram bore 406.4 mm and body outside diameter 533.4 mm. Collapsed height is 752.3 mm and extended height is 1057.1 mm. Required oil capacity is 39,525.6 cm³ and weight is approximately 988 kg (2178 lb). The plunger type is solid. The locknut allows mechanical load holding for heavy industrial lifting applications.

Features and Benefits

Lock nuts offer extended load holding
Stop ring for piston blow-out protection
Class 2 ACME thread offers high strength and easy lock-nut positioning
Thick bronze inlay on the piston flange virtually eliminates bore scoring
Swivel eye bolts are used on 100 ton and larger models

Enerpac RLN100012

Genuine, certified Enerpac product
Fast sourcing through a worldwide supply network
Product selection and compatibility support from our technical team
Equivalent and alternative product suggestions
Quotation and lead time tailored to your request

Specifications

Required Oil Capacity39525,6 cm³ (2412.0 in³)

Ram Bore Diameter406,4 mm (16 in)

Maximum Operating Pressure700 bar (10,000 psi)

Product TypeLocknut Cylinder

SeriesRLN - discontinued

Pressure at Capacity686 bar (9950 psi)

Product LineHydraulic Tools

Weight1232,9 kg (2178.0 lbs)

Cylinder Class1000 ton

Base to Port Centerline (E)108 mm (4.25 in)

Body Outside Diameter (C)533,4 mm (21 in)

Cylinder Effective Area1297,2 cm² (201.06 in²)

Extended Height (B)1057,1 mm (41.62 in)

Capacity8896,4 kN (1000 ton)

Plunger TypeSolid

Collapsed Height (A)752.3 mm (29.62 in)

Cylinder MaterialSteel

Piston Outside Diameter (D)376,2 mm (14.81 in)

Stroke304.8 mm (12.00 in)

Return TypeSingle-Acting, Load Return
