How can I get a price quote for Enerpac P143?

You can request a fast quote for Enerpac P143 from Yılsa Engineering. Reference part number YLS7XHU31QZGOOH. Submit a request via the contact or quote form and our team replies shortly with price and lead time.

Is Enerpac P143 in stock and what is the delivery time?

Yılsa Engineering sources products as genuine items through a wide supplier network. Typical lead time is 7-21 days, with 1-3 business days domestic transit in Türkiye. Current status is confirmed in the quote.

Is Enerpac P143 genuine and new?

Yes. This Enerpac product is supplied genuine and brand-new, sold with invoice under Yılsa Engineering assurance.

How do I get the datasheet and technical specs for Enerpac P143?

Key technical specifications are listed on the product page. For the full datasheet, dimensions and compatibility, simply contact Yılsa Engineering.

Click to zoom

Photo may not represent actual item. Refer to name and product specs for all details.

Enerpac P143 700 bar Hand Pump

Enerpac P143; 700 bar max pressure, 2600 cm³ usable oil, 4 cm³/stroke at 700 bar, two-speed heavy duty steel hydraulic hand pump for single-acting tools.

EnerpacMFR # P143SKU # YLS7XHU31QZGOOH

Country of OriginTaiwan

2nd Stage Pressure Rating700 bar (10,000 psi)

Dimension C616 mm (24.25 in)

Usable Oil Capacity2600 cm³ (159 in³)

Oil Displacement per Stroke (2nd Stage)4 cm³ (0.24 in³)

Maximum Operating Pressure700 bar (10,000 psi)

Have questions?Chat on WhatsApp

About This Product

The P143 is a two-speed, heavy duty steel hydraulic hand pump from the P Steel series. It is designed for use with single-acting hydraulic tools and is manually operated. It delivers 46 cm³ per stroke in the first stage (up to 28 bar) and 4 cm³ per stroke at 700 bar in the second stage. Usable oil capacity is 2600 cm³ (159 in³) and weight is 12.7 kg. Its heavy duty metal construction and large reservoir suit workshop, maintenance and field applications powering single-acting cylinders and tools.

Features and Benefits

Heavy duty metal construction for durability
Two-speed operation: 46 cm³/stroke first stage, 4 cm³/stroke second stage
Low, back-saving handle effort
Large reservoir: 2600 cm³ usable oil
700 bar (10,000 psi) maximum operating pressure, compatible with single-acting tools

Enerpac P143

Genuine, certified Enerpac product
Fast sourcing through a worldwide supply network
Product selection and compatibility support from our technical team
Equivalent and alternative product suggestions
Quotation and lead time tailored to your request

Specifications

Country of OriginTaiwan

2nd Stage Pressure Rating700 bar (10,000 psi)

Dimension C616 mm (24.25 in)

Usable Oil Capacity2600 cm³ (159 in³)

Oil Displacement per Stroke (2nd Stage)4 cm³ (0.24 in³)

Maximum Operating Pressure700 bar (10,000 psi)

Dimension B692 mm (27.25 in)

Oil Displacement per Stroke (1st Stage)46 cm³ (2.81 in³)

1st Stage Pressure Rating28 bar (400 psi)

Product TypeHand Pump - Heavy Duty Steel

SeriesP Steel

Pump Power SourceManual

Model Type159 in3 Capacity, Single-acting Compatible, Heavy Duty Steel, 10,000 psi

Cylinder CompatibilitySingle-Acting

Dimension A656 mm (25.81 in)

Product LineHydraulic Tools

Weight12,7 kg (28 lbs)

Alternative Names & Search Terms

P143P 143Enerpac P143Simplex P143Enerpac Simplex P143P143 hydraulic hand pumpP143 pumpP143 two speed pumpSimplex P seriesEnerpac P Steel seriesP Steel hand pumptwo speed hydraulic hand pump700 bar hydraulic hand pumphand pump for single-acting cylinders2600 cm³ oil capacity hand pumpheavy duty steel hydraulic hand pump10,000 psi hand pumpmanual hydraulic pump 700 bar
