Enerpac MM1250E 1270 mm Flange Facing Machine
Enerpac MM1250E; 0-1270 mm (0-50") facing diameter, pneumatic-driven external mount flange facing machine.
Dimension G410 mm (16.1 in)
Dimension E1001 mm (39.4 in)
Tool Post Stroke Z-Axis0 - 102 mm (0 - 4 in)
Dimension F362 mm (14.25 in)
Dimension D1593 mm (62.7 in)
Clamping Range967 - 1283 mm (38.1 - 50.5 in)
About This Product
MM1250E is an external mount flange facing machine from the MME series. It offers a 0-1270 mm (0-50") facing diameter and produces continuous groove gramophone finishes to ASME standard.
The standard drive is pneumatic, with a 90 psi (approx. 6.2 bar) supply requirement and a maximum speed of 9 rpm. The clamping range is 967-1283 mm, tool post stroke is 0-102 mm on the Z axis and 0-356 mm on the X axis, and feed rate is 0.1-0.8 mm/rev. The machine has 8 clamping locators.
It is used for facing heat exchanger flanges and other large flanges such as crane pedestals.
Features and Benefits
- Robust external mount flange facing machine with ASME standard gramophone finishes
- Continuous variable auto-feed (0.1-0.8 mm/rev)
- Quick-set radial clamping and axial adjustment jaws
- Heavy duty bearing construction for high metal removal rates and accuracy
- Heat exchanger kits for back facing and slot machining in one operation
Enerpac MM1250E
- Genuine, certified Enerpac product
- Fast sourcing through a worldwide supply network
- Product selection and compatibility support from our technical team
- Equivalent and alternative product suggestions
- Quotation and lead time tailored to your request
Specifications
Dimension G410 mm (16.1 in)
Dimension E1001 mm (39.4 in)
Tool Post Stroke Z-Axis0 - 102 mm (0 - 4 in)
Dimension F362 mm (14.25 in)
Dimension D1593 mm (62.7 in)
Clamping Range967 - 1283 mm (38.1 - 50.5 in)
Minimum Facing Diameter0 mm
Dimension C1295 mm (51 in)
Dimension B1052 - 737 mm (41.4 - 29 in)
Clamping Locators8
Drive TypePneumatic
Dimension I455 mm (17.9 in)
Dimension H168 mm (6.6 in)
Product TypeOutside Mount Flange Facing Machines
Supply Required6.2 bar (90 psi)
Tool Post Stroke X-Axis0 - 14 in
SeriesMME
Max. Speed9 rpm
Tool Post Stroke (X Axis)0 - 356 mm
Maximum Facing Diameter1270 mm
X & Y Axis Feed Rate per Rev0.1 - 0.8 mm (0.004 - 0.31 in)
Dimension A967 - 1283 mm (38.1 - 50.5 in)
Min. Facing Diameter0 in
Product LineMachining Tools
Weight650 kg (1434 lbs)
Max. RPM (300 scfm)26 rpm
Max. Facing Diameter50 in
