Enerpac G5745 700 bar Air Hydraulic Pump

G5745 is a continuous-duty air hydraulic pump from the Simplex G5 Air series. With its 5 gallon reservoir, it is designed for mid sized double-acting hydraulic cylinders and tools. The pump is driven by a 3 hp (cv), 3,000 rpm rotary vane air motor. The motor consumes 1.42 m³/min (50 cfm) of air at 6 bar (90 psi). The two-stage pump delivers 700 in³/min in the 1st stage up to approx. 76 bar (1,100 psi). In the 2nd stage it delivers 901.3 cm³/min (55 in³/min) at 700 bar (10,000 psi). The valve is a 4-way, 3-position manual valve. Usable oil capacity is 18.93 l (5 gal) and weight is 49 kg. A filter-lubricator assembly, air muffler, carry handlebar and external adjustable relief valve come standard. The larger reservoir suits double-acting cylinders that need more oil volume.
