How can I get a price quote for Enerpac G3172T?

You can request a fast quote for Enerpac G3172T from Yılsa Engineering. Reference part number YLSMPFEMSFXMLKL. Submit a request via the contact or quote form and our team replies shortly with price and lead time.

Is Enerpac G3172T in stock and what is the delivery time?

Yılsa Engineering sources products as genuine items through a wide supplier network. Typical lead time is 7-21 days, with 1-3 business days domestic transit in Türkiye. Current status is confirmed in the quote.

Is Enerpac G3172T genuine and new?

Yes. This Enerpac product is supplied genuine and brand-new, sold with invoice under Yılsa Engineering assurance.

How do I get the datasheet and technical specs for Enerpac G3172T?

Key technical specifications are listed on the product page. For the full datasheet, dimensions and compatibility, simply contact Yılsa Engineering.

Click to zoom

Photo may not represent actual item. Refer to name and product specs for all details.

Enerpac G3172T 700 bar Torque Wrench Pump

Enerpac G3172T; 700 bar, 753.8 cm³/min oil flow, 5.68 l usable oil, 4/2 solenoid valve, 115 V electric hydraulic torque wrench pump.

EnerpacMFR # G3172TSKU # YLSMPFEMSFXMLKL

Output Flow Rate 1st Stage8603,2 cm³/min (525 in³/min)

Country of OriginUnited States

2nd Stage Pressure Rating700 bar (10,000 psi)

Dimension D151,4 mm (5.96 in)

Dimension C482,6 mm (19 in)

Maximum Operating Pressure700 bar (10,000 psi)

Have questions?Chat on WhatsApp

About This Product

The G3172T is a two-stage electric torque wrench pump from the G3 TW series. It has a 4-way, 2-position solenoid valve. Maximum operating pressure is 700 bar (10,000 psi), with an oil flow of 753.8 cm³/min at that pressure; first stage pressure is 1,100 psi (approx. 76 bar). The pump is driven by a 115 V, 60 Hz, 1.13 hp universal motor and draws 16 A at full load. Usable oil capacity is 5.68 l (1.5 gal) and weight is 28.1 kg. It is used with small to mid-sized hydraulic torque wrenches in bolting applications. The two-stage design provides a higher crossover pressure for faster cycle times and tool operation.

Features and Benefits

Heavy duty bolting pump for small to mid-sized torque wrenches
753.8 cm³/min oil flow at 700 bar
Two-stage design with higher crossover pressure for faster cycles
4/2 solenoid valve
115 V, 60 Hz, 1.13 hp universal motor; 16 A at full load
5.68 l usable oil, 28.1 kg

Enerpac G3172T

Genuine, certified Enerpac product
Fast sourcing through a worldwide supply network
Product selection and compatibility support from our technical team
Equivalent and alternative product suggestions
Quotation and lead time tailored to your request

Specifications

Output Flow Rate 1st Stage8603,2 cm³/min (525 in³/min)

Country of OriginUnited States

2nd Stage Pressure Rating700 bar (10,000 psi)

Dimension D151,4 mm (5.96 in)

Dimension C482,6 mm (19 in)

Maximum Operating Pressure700 bar (10,000 psi)

Dimension B222,3 mm (8.75 in)

Motor Voltage115 V

Usable Oil Capacity5,68 l (1.5 gal)

Motor Frequency60 Hz

1st Stage Pressure Rating76 bar (1,100 psi)

Product TypeTorque Wrench Pump - Electric

Output Flow Rate 2nd Stage753,8 cm³/min (46 in³/min)

Valve OperationSolenoid

Pump Valve Type4-Way, 2-Position

Motor Size1.13 hp

SeriesG3 TW (Discontinued)

Pump Power SourceElectric

Current Draw16 A

Dimension A384,3 mm (15.13 in)

Product LineBolting Tools

Weight28,1 kg (62 lbs)
