How can I get a price quote for Enerpac CLP602?

You can request a fast quote for Enerpac CLP602 from Yılsa Engineering. Reference part number CEY-55221B11A488. Submit a request via the contact or quote form and our team replies shortly with price and lead time.

Is Enerpac CLP602 in stock and what is the delivery time?

Yılsa Engineering sources products as genuine items through a wide supplier network. Typical lead time is 7-21 days, with 1-3 business days domestic transit in Türkiye. Current status is confirmed in the quote.

Is Enerpac CLP602 genuine and new?

Yes. This Enerpac product is supplied genuine and brand-new, sold with invoice under Yılsa Engineering assurance.

How do I get the datasheet and technical specs for Enerpac CLP602?

Key technical specifications are listed on the product page. For the full datasheet, dimensions and compatibility, simply contact Yılsa Engineering.

Click to zoom

Photo may not represent actual item. Refer to name and product specs for all details.

Enerpac CLP602 60 Ton Locknut Cylinder

Enerpac CLP602; 60 ton (533.8 kN) capacity, 50 mm stroke, 700 bar, single-acting low-height pancake locknut hydraulic cylinder.

EnerpacMFR # CLP602SKU # CEY-55221B11A488

Required Oil Capacity432,6 cm³ (26.4 in³)

Base to Port Centerline F20,3 mm (0.8 in)

Saddle Diameter E96,5 mm

Ram Bore Diameter104,1 mm (4.1 in)

Maximum Operating Pressure700 bar (10,000 psi)

Saddle Diameter E3.8 in

Have questions?Chat on WhatsApp

About This Product

CLP602 is a single-acting, low-height locknut hydraulic cylinder from the Simplex CLP series, which has been discontinued. The locknut holds the lifted load mechanically. The cylinder offers 60 ton (533.8 kN) capacity, 50 mm (1.97 in) stroke and 700 bar (10,000 psi) maximum operating pressure; pressure at capacity is 617 bar. Collapsed height is 124.5 mm, extended height 170.2 mm, effective area 86.5 cm² and required oil capacity 432.6 cm³. Body outside diameter is 139.7 mm, saddle diameter 96.5 mm, piston thread 105 x 6 mm, and weight 33 lb (approx. 15 kg). It is used for lifting in confined spaces, machinery and die positioning, maintenance work and load holding applications.

Features and Benefits

Extra low profile to fit into tight spaces
5° swivel load cap on all models
Locknut design provides positive mechanical load hold
Load return with overload protection port
Carrying handles and eye bolts

Enerpac CLP602

Genuine, certified Enerpac product
Fast sourcing through a worldwide supply network
Product selection and compatibility support from our technical team
Equivalent and alternative product suggestions
Quotation and lead time tailored to your request

Specifications

Required Oil Capacity432,6 cm³ (26.4 in³)

Base to Port Centerline F20,3 mm (0.8 in)

Saddle Diameter E96,5 mm

Ram Bore Diameter104,1 mm (4.1 in)

Maximum Operating Pressure700 bar (10,000 psi)

Saddle Diameter E3.8 in

Product TypeLow Height Locknut Cylinder

SeriesCLP - discontinued

Pressure at Capacity617 bar (8955 psi)

Product LineHydraulic Tools

Weight15 kg (33.0 lbs)

Cylinder Class60 ton

Piston OD Thread D105 x 6 mm

Body Outside Diameter (C)139,7 mm (5.5 in)

Cylinder Effective Area86,5 cm² (13.4 in²)

Extended Height (B)170,2 mm (6.7 in)

Capacity533,8 kN (60 ton)

Plunger TypeSolid

Collapsed Height (A)124.5 mm (4.9 in)

Cylinder MaterialSteel

Stroke50 mm (1.97 in)

Return TypeSingle-Acting, Spring Return

Documents & CAD

For this product 2

Instruction ManualCLP-Series CylindersPDF·5.0 MB 4 languages· in one file

Repair Parts SheetCLP Low Profile Cylinders & CLL Lock Nut CylindersPDF·554 KB 4 languages· in one file

Series documents 1· shared by this product series

Repair Parts SheetCLP Series CylindersPDF·31 KB 4 languages· in one file
