Bosch Rexroth 3842564181
Dampened stopping of the first accumulating workpiece pallet
Mass [m] [kg]0.27
Operating temperature [T] max+5 … +60 °C
Workpiece pallet total weight [mG] [kg]80
Pneumatic straight connection [Ø] [mm]4
Scope of deliveryPneumatic elements
Delivery informationFully assembled
About This Product
Dampened stopping of the first accumulating workpiece pallet
Bosch Rexroth 3842564181
- Genuine, certified Bosch Rexroth product
- Fast sourcing through a worldwide supply network
- Product selection and compatibility support from our technical team
- Equivalent and alternative product suggestions
- Quotation and lead time tailored to your request
Specifications
required compressed air connection [pmax] [bar]6
required compressed air connection [pmin] [bar]4
Mass [m] [kg]0.27
Operating temperature [T] max+5 … +60 °C
Workpiece pallet total weight [mG] [kg]80
Pneumatic straight connection [Ø] [mm]4
Scope of deliveryIncl. fastening material for assembly on the conveyor section ST 2/...
Scope of deliveryPneumatic elements
Delivery informationFully assembled
Material informationHousing: Plastic
Material informationStop cam: Steel, hardened
Min. workpiece pallet weight m1 kg
Pneumatic circuit diagram1 Not included in the scope of delivery
Opening/shutting times1 Close
Opening/shutting times2 Open at 4 bar
Opening/shutting timesl = Hose length
Maximum permissible mass workpiece pallet mG at nominal speed vN 6 m/min80 kg
Maximum permissible mass workpiece pallet mG at nominal speed vN 9 m/min60 kg
Maximum permissible mass workpiece pallet mG at nominal speed vN 12 m/min40 kg
Maximum permissible mass workpiece pallet mG at nominal speed vN 15 m/min26 kg
Maximum permissible mass workpiece pallet mG at nominal speed vN 18 m/min18 kg
Recommended accessoriesPosition inquiry VE 2/D-80
Recommended accessoriesSwitch bracket for WT position inquiry
Recommended accessoriesVE 2/RS Return Stop
Weight [kg]0.41
Documents & CAD
For this product 4
