Baldor WDGF1021AG Right Angle Worm Gear
Right Angle Worm Gear Speed Reducer - Single Reduction, 10:1 Ratio, 2.06 in Center Distance, C-Face Quill, 0.6300 in Input Size, Left Hand Output, 56C Frame
ITEM #690744a5c29ded7b22b7b1d9 MFR #WDGF1021AG SKU #YLSMUJ7OAICU8N0
Quick Specs
Center Distance: 2.0600 in
Reduction: Single
Ratio: 10:1
Max Input Horsepower: 2.200 hp @ 1750 rpm
Input Type: C-Face Quill
Input Size: 0.6250 in
Overview
Right Angle Worm Gear Speed Reducer - Single Reduction, 10:1 Ratio, 2.06 in Center Distance, C-Face Quill, 0.6300 in Input Size, Left Hand Output, 56C Frame
Specifications
Center Distance 2.0600 in
Reduction Single
Ratio 10:1
Max Input Horsepower 2.200 hp @ 1750 rpm
Input Type C-Face Quill
Input Size 0.6250 in
Output Type Solid
Output Size 1.0000 in
Output Direction Left Hand
NEMA / IEC Frame Size 56C
Maximum Output RPM 175.000 @ 1750 rpm input
Maximum Output Torque 630 in-lbs
Housing Material Cast Iron
Overhung Load Capacity 750 lb
Housing Dimensions 6.06 x 4.84 x 6.38 in
Housing Height 6.38 in
Housing Length 6.38 in
Housing Width 4.84 in
Includes Klubersynth UHI-6-460 Synthetic Oil
Manufacturer Reducer Size 921
Mounting Type Basic Gear Reducer Drive
UPC_NO 781568195949
Weight 35.00 lbs
