How can I get a price quote for Baldor GIF1838B?

You can request a fast quote for Baldor GIF1838B from Yılsa Engineering. Reference part number YLS2FVUDPER2RT. Submit a request via the contact or quote form and our team replies shortly with price and lead time.

Is Baldor GIF1838B in stock and what is the delivery time?

Yılsa Engineering sources products as genuine items through a wide supplier network. Typical lead time is 7-21 days, with 1-3 business days domestic transit in Türkiye. Current status is confirmed in the quote.

Is Baldor GIF1838B genuine and new?

Yes. This Baldor product is supplied genuine and brand-new, sold with invoice under Yılsa Engineering assurance.

How do I get the datasheet and technical specs for Baldor GIF1838B?

Key technical specifications are listed on the product page. For the full datasheet, dimensions and compatibility, simply contact Yılsa Engineering.

Click to zoom

Photo may not represent actual item. Refer to name and product specs for all details.

Baldor GIF1838B

Baldor GIF1838B (HB382CN140TC) is a right-angle helical gear reducer with a 17.33 ratio, 1947 IN/LBS torque rating and 140TC mounting.

BaldorMFR # GIF1838BSKU # YLS2FVUDPER2RTDiscontinued

Output torque1947.00 lb-in

Product seriesQUANTIS

Product sizeQUA38

Reducer gear ratio17.550

Input power3.12 HP

Input speed (rpm)1750 rpm

Have questions?Chat on WhatsApp

About This Product

Baldor GIF1838B (HB382CN140TC) is a right-angle helical gear reducer with a 17.33 ratio, 1947 IN/LBS torque rating and 140TC mounting.

Baldor GIF1838B

Genuine, certified Baldor product
Fast sourcing through a worldwide supply network
Product selection and compatibility support from our technical team
Equivalent and alternative product suggestions
Quotation and lead time tailored to your request

Specifications

Output torque1947.00 lb-in

Product seriesQUANTIS

Product sizeQUA38

Reducer gear ratio17.550

Input power3.12 HP

Input speed (rpm)1750 rpm

Lubricant typeSTD

Motor mountNEMA 140

Mounting positionA1

Operations manualMN1697

Shaft size1.0000 IN

Style numberHB382CN140TC

UPC781568438992

Documents & CAD

For this product 1

DatasheetDatasheetPDF·113 KB·English

Spare Parts 5

The genuine spare parts used for servicing and repairing the Baldor GIF1838B motor are listed below. The list is based on the parts list published by the manufacturer for this motor; each part is shown with its code, description and the quantity used in the motor. Click a part number to see its technical details and the other motors that use the same part. Quoting the catalog and spec numbers from the nameplate with your spare-part order helps us supply the correct part. Request a quote for price and lead time.

Part no	Description	Quantity	Used in
083890	Z38 ADPTR MODULE 71-100	1 pcs	2 motors
088065	HB38G4.73-1.000", ILH	1 pcs	2 motors
086835	NEMA 140TC CLAMP COLLAR	1 pcs	2 motors
370109	RIG-44/1.5/3.67/49,GEAR	1 pcs	1 motors
083440	RIP-12/1.5/12,PINION	1 pcs	1 motors
